Product Details | E SPECIAL PURPOSE CABLE ASSEMBLY
5995-01-599-8657 A definite continuous length of CABLE, SPECIAL PURPOSE, ELECTRICAL, having one or more ends processed or terminated in fittings which provide for connection to other items. Excludes items having branches or forks. Excludes LEAD, TEST and CABLE AND CONDUIT ASSEMBLY, ELECTRICAL.20611350043Fuzing and Firing Devices, Nuclear Ordnance11900057Specialized Test and Handling Equipment, Nuclear Ordnance132500004935000059950057Cable, Cord, and Wire Assemblies: Communication Equipment61500055Miscellaneous Electric Power and Distribution Equipment
Part Alternates: 500506, 5995-01-599-8657, 01-599-8657, 5995015998657, 015998657
Electrical and Electronic Equipment Components | Cable, Cord, and Wire Assemblies: Communication Equipment
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 26 OCT 2011 | 01-599-8657 | 00782 ( CABLE ASSEMBLY, SPECIAL PURPOSE, ELECTRICAL ) |
Drawings & Photos | NSN 5995-01-599-8657
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 5995-01-599-8657
Technical Data | NSN 5995-01-599-8657
| Characteristic | Specifications |
|---|---|
| TERMINAL LUG APERTURE SIZE | 0.144 INCHES 2ND END ALL CONDUCTORS |
| TERMINAL COMMERCIAL AND GOVERNMENT ENTITY CODE | 56501 2ND END ALL CONDUCTORS |
| ROUND CONDUCTOR SIZE | 20 AWG ALL CONDUCTORS |
| CROSS-SECTIONAL SHAPE STYLE | ROUND |
| STRAND QUANTITY PER CONDUCTOR | 7 ALL CONDUCTORS |
| MATERIAL | COPPER CORE CONDUCTOR ALL CONDUCTORS |
| END ITEM IDENTIFICATION | WEATHERPAC 500 |
| OUTSIDE DIAMETER | 0.654 INCHES NOMINAL ALL CONDUCTORS |
| TERMINATION TYPE | LUG TERMINAL W/MOUNTING HOLE 2ND END ALL CONDUCTORS |
| TERMINAL MANUFACTURER IDENTIFYING REFERENCE NUMBER | RA-484 2ND END ALL CONDUCTORS |
| TERMINATION TYPE | LUG TERMINAL W/MOUNTING HOLE 1ST END ALL CONDUCTORS |
| SPECIAL FEATURES | CABLE IS M24643/13-01UN (NSN 6145-01-202-2831; EACH END HAS 4 WIRES INDIVIDUALLY TERMINATED WITH A TERMINAL, LUG, CRIMP, SIZE 18-22, NO 6 STUD (RED), SAE-AS17143-13; 1ST END: PANEL MOUNT DISPLAY; 2ND END: TERMINAL BOX |
| STRAND AWG SIZE PER CONDUCTOR | 28 ALL CONDUCTORS |
| OVERALL LENGTH | 50.0 FEET |
| CONDUCTOR FORM | STRANDED ALL CONDUCTORS |
| PART NAME ASSIGNED BY CONTROLLING AGENCY | DRAWING: CABLE ASSEMBLY C-HD/HE-4 |
| CONDUCTOR QUANTITY | 4 |
Restrictions/Controls & Freight Information | NSN 5995-01-599-8657
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Electro-static Discharge Susceptible: | A | No known Electrostatic Discharge (ESD) or Electromagnetic Interference (EMI) sensitivity |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
| Category | Code | Description |
|---|---|---|
| NMF Description | 061130 | CABLE ASSEMBLY |
| Less than car load rating | ||
| Less than truck load rating | P | 77.5 |
| Water commodity Code | 743 | unknown |
| Originating Activity Code | HD | Naval Inventory Control Point Mechanicsburg, PA 17055-0788 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | H | Signal Corps supplies and equipment, including radio equipment and supplies, communications equipment and supplies, electrical equipment and supplies, etc. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
