NSN 5985-01-372-8881 161A7201, 161A720-1, 44000
Product Details | RADIO FREQUENCY POWER DIVIDER
5985-01-372-8881 An item specifically designed to separate incoming radio frequency power into predetermined proportional values at its output terminals.20358950037Miscellaneous Communication Equipment59850043Antennas, Waveguides, and Related Equipment66250070Electrical and Electronic Properties Measuring and Testing Instruments
Part Alternates: 161A7201, 161A720-1, 44000, 5985-01-372-8881, 01-372-8881, 5985013728881, 013728881
Electrical and Electronic Equipment Components | Antennas, Waveguides, and Related Equipment
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 22 MAR 1993 | 01-372-8881 | 60411 ( DIVIDER, POWER, RADIO FREQUENCY ) |
Drawings & Photos | NSN 5985-01-372-8881
Demand History | NSN 5985-01-372-8881
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 44000 | 2017-01-31 | 5 | |
| 44000 | 2011-01-15 | 1 | |
| 44000 | 2010-10-294 | 51 |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 5985-01-372-8881
Related Products | NSN 5985-01-372-8881
Technical Data | NSN 5985-01-372-8881
| Characteristic | Specifications |
|---|---|
| FREQUENCY RATING | 0.5 GIGAHERTZ MINIMUM AND 2.0 GIGAHERTZ MAXIMUM |
| OUTPUT QUANTITY | 5 |
| POWER RATING | 17.0 WATTS AVERAGE |
| VOLTAGE STANDING WAVE RATIO | 1.30 AND 1.50 |
| INSERTION LOSS IN DECIBELS | 1.0 |
| COAXIAL CONNECTOR SERIES DESIGNATION | SMA |
| MOUNTING FACILITY TYPE AND QUANTITY | 4 UNTHREADED HOLE |
| OVERALL LENGTH | 4.750 INCHES NOMINAL |
| OVERALL HEIGHT | 0.350 INCHES MINIMUM AND 0.390 INCHES MAXIMUM |
| OVERALL WIDTH | 2.390 INCHES MINIMUM AND 2.410 INCHES MAXIMUM |
| SPECIAL FEATURES | 20 DB ISOLATION; 50 OHMS IMPEDANCE |
Restrictions/Controls & Freight Information | NSN 5985-01-372-8881
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | P | There is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Electro-static Discharge Susceptible: | B | ESD sensitivity |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 116030 | MACHINES ETC DATA PROCESSING |
| Less than car load rating | ||
| Less than truck load rating | W | Rating Variable |
| Water commodity Code | 72D | unknown |
| Originating Activity Code | TH | Defense Supply Center Columbus Columbus, OH 43215 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | H | Signal Corps supplies and equipment, including radio equipment and supplies, communications equipment and supplies, electrical equipment and supplies, etc. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 5985-01-372-8881
Air Force| Category | Code | Description |
|---|---|---|
| Budget Code | 9 | General Support DIV57X4921.070:Air Force decentrally managed expense items (ERRC XB3, XF-3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors. |
| Materiel Management Aggregation Code | EH | SX:ELECTRONIC COMPONENTS |
| Price Validation | N | The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
|
| Fund Code | SF | Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point. |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DF | Department of the Air Force |
| Service Organization | F | U.S. Air Force |
| Reparability | N | Stock Fund (except Munitions) |
| Acquisition Advice Codes | J | NOT STOCKED, CENTRALLY PROCURED # (NON-STOCKED ITEMS) IMM/Service centrally managed but not stocked item. Procurement will be initiated only after receipt of a requisition. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
