NSN 5985-01-142-3405 M2D4500S001, M2D4500-S001, MA48682
Product Details | RADIO FREQUENCY CIRCULATOR
5985-01-142-3405 A waveguide, stripline, or coaxial component having three or more ports (terminals), so arranged that energy entering one port is transmitted to the next adjacent port in a particular direction while decoupling the energy from all other ports. Excludes SWITCH, RADIO FREQUENCY TRANSMISSION LINE; and SWITCH, WAVEGUIDE.
Part Alternates: M2D4500S001, M2D4500-S001, MA48682, MA-48682, CT4718OT, CT-4718-OT, 9509471, 950947-1, 10461X1031, 10461X-1031, 5985-01-142-3405, 01-142-3405, 5985011423405, 011423405
Electrical and Electronic Equipment Components | Antennas, Waveguides, and Related Equipment
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 14 NOV 1982 | 01-142-3405 | 31842 ( CIRCULATOR, RADIO FREQUENCY ) |
Drawings & Photos | NSN 5985-01-142-3405
Demand History | NSN 5985-01-142-3405
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 5985-01-142-3405 | 2017-03-61 | 24 | DIBBS |
| 5985-01-142-3405 | 2008-07-183 | 14 | DIBBS |
| 5985-01-142-3405 | 2008-04-94 | 39 | DIBBS |
| 5985-01-142-3405 | 2007-11-319 | 1 | United States |
| 5985-01-142-3405 | 2007-11-316 | 1 | us |
| 5985-01-142-3405 | 2007-10-291 | 63 | DIBBS |
| 5985-01-142-3405 | 2007-06-157 | 49 | DIBBS |
| 5985-01-142-3405 | 2007-04-103 | 108 | DIBBS |
Cross Reference | NSN 5985-01-142-3405
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 10461X-1031 | 27338 | CRANE ELECTRONICS, INC. DBA STC MICROWAVE SYSTEMS |
| 950947-1 | 21847 | FEI MICROWAVE INC |
| 950947-1 | 27338 | CRANE ELECTRONICS, INC. DBA STC MICROWAVE SYSTEMS |
| 950947-1 | 3B150 | RAYTHEON TECHNICAL SERVICES COMPANY LLC |
| 950947-1 | 49956 | RAYTHEON COMPANY DBA RAYTHEON |
| 950947-1 | 50310 | RYT INDUSTRIES INC |
| 950947-1 | 58202 | CRANE ELECTRONICS, INC. DBA STC MICROWAVE SYSTEMS |
| 950947-1 | 60583 | L-3 COMMUNICATIONS CORPORATION DBA NARDA MICROWAVE WEST |
| 950947-1 | 96341 | COBHAM ELECTRONIC SYSTEMS INC. DBA COBHAM DEFENSE ELECTRONICS |
| CT-4718-OT | 23261 | UTE MICROWAVE INC |
| M2D4500-S001 | 96341 | COBHAM ELECTRONIC SYSTEMS INC. DBA COBHAM DEFENSE ELECTRONICS |
| MA-48682 | 96341 | COBHAM ELECTRONIC SYSTEMS INC. DBA COBHAM DEFENSE ELECTRONICS |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 5985-01-142-3405
Related Products | NSN 5985-01-142-3405
Technical Data | NSN 5985-01-142-3405
| Characteristic | Specifications |
|---|---|
| FREQUENCY RANGE RATING | 4.4 TO 5.0 GIGAHERTZ |
| OVERALL LENGTH | 1.580 INCHES NOMINAL |
| OVERALL WIDTH | 1.000 INCHES NOMINAL |
| OVERALL HEIGHT | 0.500 INCHES NOMINAL |
| CONNECTION METHOD | CONNECTOR RECEPTACLE |
| CONNECTOR QUANTITY | 2 |
| TRADE DESIGNATION | CONNECTOR,RECEPTACLE |
| IDENTIFYING NUMBER | SMA TYPE NO. |
| IMPEDANCE RATING IN OHMS | NOT RATED |
| INSERTION LOSS IN DECIBELS | 0.3 |
| III END ITEM IDENTIFICATION | AN/TRC-170 |
