NSN 5985-01-126-6838 77230332, 77-230332, 01-126-6838
Product Details | RADIO FREQUENCY TRANSMISSION LINE SWITCH
5985-01-126-6838 An item specifically designed for mechanically or electronically positioning one or more radio frequency transmission line sections so as to couple it or them to other sections in a radio frequency transmission line system. The switching function may be operated by a manual actuator, an electromechanical actuator or by means of an arrangement of semiconductors and passive circuit devices. Excludes RELAY, (as modified).202593000005985000000
Part Alternates: 77230332, 77-230332, 5985-01-126-6838, 01-126-6838, 5985011266838, 011266838
Electrical and Electronic Equipment Components | Antennas, Waveguides, and Related Equipment
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 15 FEB 1982 | 01-126-6838 | 05298 ( SWITCH, RADIO FREQUENCY TRANSMISSION LINE ) |
Drawings & Photos | NSN 5985-01-126-6838
Cross Reference | NSN 5985-01-126-6838
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 77-230332 | 00471 | DOW-KEY MICROWAVE CORPORATION |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 5985-01-126-6838
Technical Data | NSN 5985-01-126-6838
| Characteristic | Specifications |
|---|---|
| ACTUATOR VOLTAGE IN VOLTS | 19.0 MINIMUM AND 31.0 MAXIMUM |
| SWITCH TYPE | TRANSFER |
| COUPLING POSITION QUANTITY | 3 |
| TERMINAL TYPE AND QUANTITY | 2 TAB, SOLDER LUG |
| COAXIAL CONNECTOR SERIES DESIGNATION | N |
| SWITCHING TIME | 15.0 MILLISECONDS |
| BODY STYLE | 17B RECTANGULAR |
| OVERALL HEIGHT | 2.200 INCHES NOMINAL |
