Product Details | WAVEGUIDE SUPPORT
5985-00-825-1815 An item which consists of a mechanical or structural part designed to overcome the force of gravity, but is not intended to be the principal sustaining member of a waveguide.
Part Alternates: 2652011, 414194, 4141943, 414194-3, 68003, 9017103, 5985-00-825-1815, 00-825-1815, 5985008251815, 008251815
Electrical and Electronic Equipment Components | Antennas, Waveguides, and Related Equipment
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 01 JAN 1963 | 00-825-1815 | 02494 ( SUPPORT, WAVEGUIDE ) |
Drawings & Photos | NSN 5985-00-825-1815
Demand History | NSN 5985-00-825-1815
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 5985-00-825-1815 | 2022-03-68 | 3 | United States |
| 5985-00-825-1815 | 2018-09-271 | 1 | US |
| 5985-00-825-1815 | 2017-06-178 | 2 | US |
| 5985-00-825-1815 | 2017-06-177 | 1 | DIBBS |
| 5985-00-825-1815 | 2017-06-166 | 2 | DIBBS |
| 5985-00-825-1815 | 2017-05-144 | 4 | DIBBS |
| 5985-00-825-1815 | 2017-05-129 | 5 | DIBBS |
| 5985-00-825-1815 | 2016-08-241 | 2 | DIBBS |
| 5985-00-825-1815 | 2013-10-274 | 20 | United Kingdom |
| 5985-00-825-1815 | 2012-04-94 | 6 | DIBBS |
| 5985-00-825-1815 | 2012-01-25 | 5 | DIBBS |
| 5985-00-825-1815 | 2011-08-231 | 3 | DIBBS |
| 5985-00-825-1815 | 2010-01-11 | 10 | United Kingdom |
| 5985-00-825-1815 | 2009-02-36 | 10 | United Kingdom |
| 5985-00-825-1815 | 2008-12-352 | 41 | DIBBS |
| 5985-00-825-1815 | 2008-09-255 | 33 | DIBBS |
| 5985-00-825-1815 | 2008-06-182 | 1 | United Kingdom |
| 5985-00-825-1815 | 2008-05-148 | 10 | United Kingdom |
| 5985-00-825-1815 | 2008-03-73 | 2 | US |
| 5985-00-825-1815 | 2008-01-03 | 104 | DIBBS |
| 5985-00-825-1815 | 2007-12-351 | 104 | DIBBS |
| 5985-00-825-1815 | 2007-08-221 | 88 | DIBBS |
| 5985-00-825-1815 | 2007-07-200 | 44 | DIBBS |
| 5985-00-825-1815 | 2007-05-145 | 32 | DIBBS |
Cross Reference | NSN 5985-00-825-1815
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 2652011 | 06424 | ALLIANT TECHSYSTEMS OPERATIONS LLC DIV DEFENSE ELECTRONIC SYSTEMS |
| 2652011 | 56232 | LOCKHEED MARTIN CORPORATION DBA LOCKHEED MARTIN |
| 414194 | 96214 | RAYTHEON COMPANY DBA RAYTHEON |
| 414194-3 | 96214 | RAYTHEON COMPANY DBA RAYTHEON |
| 68003 | 66544 | CONTINENTAL MICROWAVE AND TOOL CO., INC. |
| 68003 | 80006 | LITTON SYSTEMS INC AIRTRON DIV |
| 9017103 | 18876 | U S ARMY AVIATION AND MISSILE COMMAND |
