NSN 5980-01-314-6424 DNM10007606, DNM-100-076-06, DNM10007608
Product Details | OPTOELECTRONIC CONTROL-DISPLAY
5980-01-314-6424 A item composed of a DISPLAY, OPTOELECTRONIC and an integral CONTROL, OPTOELECTRONIC, that performs the dual function of controlling the operational mode of, and presenting numeric, alphanumeric, symbolic, or graphic characters on an optoelectronic display. For items that do not include a control device, see DISPLAY, OPTOELECTRONIC. For items which are designed to display quantitative information in a specific format, see INDICATOR (as modified), and CONTROL-INDICATOR.
Part Alternates: DNM10007606, DNM-100-076-06, DNM10007608, DNM-100-076-08, 6276032, 627603-2, 5980-01-314-6424, 01-314-6424, 5980013146424, 013146424
Electrical and Electronic Equipment Components | Optoelectronic Devices and Associated Hardware
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 02 FEB 1990 | 01-314-6424 | 37200 ( CONTROL-DISPLAY, OPTOELECTRONIC ) |
Drawings & Photos | NSN 5980-01-314-6424
Demand History | NSN 5980-01-314-6424
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 5980-01-314-6424 | 2014-06-156 | 1 | United States |
| 6276032 | 2014-05-128 | 1 | United States |
| 6276032 | 2014-05-128 | 1 | United States |
| 6276032 | 2010-07-211 | 2 | United States |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 5980-01-314-6424
Technical Data | NSN 5980-01-314-6424
| Characteristic | Specifications |
|---|---|
| CONTROL TYPE | DRIVER |
| DISPLAY TYPE | LIQUID CRYSTAL |
| CHARACTER TYPE | ALPHANUMERIC |
| LINE QUANTITY | 1 |
| CHARACTER QUANTITY PER LINE | 6 |
| DISPLAY COLOR | GREEN |
| VOLTAGE RATING | 28.0 VOLTS NOMINAL |
| TERMINAL TYPE AND QUANTITY | 14 PIN |
| OVERALL LENGTH | 2.668 INCHES NOMINAL |
| OVERALL WIDTH | 1.320 INCHES NOMINAL |
| OVERALL HEIGHT | 0.930 INCHES NOMINAL |
| SPECIAL FEATURES | ELECTROSTATIC SENSITIVE |
| TEST DATA DOCUMENT | 37695-627603 DRAWING |
