NSN 5980-01-170-1544 A30886523, A3088652-3, HLMP3401
Product Details | LIGHT EMITTING DIODE
5980-01-170-1544 A two electrode, solid state, optoelectronic device that emits visible or infrared radiant energy when electrically energized. May or may not include mounting hardware and/or heat sink. Excludes LAMP, CARTRIDGE; and LIGHT, INDICATOR. For solid state devices which are responsive to infrared or radiant energy, see SEMICONDUCTOR DEVICE (1), PHOTO.20259800046Optoelectronic Devices and Associated Hardware62100045Indoor and Outdoor Electric Lighting Fixtures
Part Alternates: A30886523, A3088652-3, HLMP3401, HLMP-3401, HP50824555, HP5082-4555, SC/A4/90179, SCA490179, FV05881, FV35611, 99130797, 0238741G00, 210079, 28020001001, 280-20001-001, 3130134G002, 4460090002, 446009-0002, 50824555, 5082-4555, 520/4/00372/000, 520400372000, 5219248, 521-9248, 5394806, 539480-6, 5980-01-170-1544, 01-170-1544, 5980011701544, 011701544
Electrical and Electronic Equipment Components | Optoelectronic Devices and Associated Hardware
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 20 JAN 1984 | 01-170-1544 | 32371 ( LIGHT EMITTING DIODE ) |
Drawings & Photos | NSN 5980-01-170-1544
Demand History | NSN 5980-01-170-1544
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 5980-01-170-1544 | 2017-10-299 | 1 | United States |
| 5980-01-170-1544 | 2017-10-289 | 3 | United States |
| 5980-01-170-1544 | 2017-10-289 | 3 | United States |
| 5980-01-170-1544 | 2009-12-363 | 304 | DIBBS |
Cross Reference | NSN 5980-01-170-1544
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 0238741G00 | F0555 | MBDA FRANCE |
| 210079 | 21793 | ASTRONICS TEST SYSTEMS INC. |
| 280-20001-001 | 81205 | THE BOEING COMPANY DBA BOEING |
| 3130134G002 | 28526 | CUP-PAC CO |
| 446009-0002 | 65597 | THALES DEFENSE & SECURITY, INC. |
| 5082-4555 | 28480 | HEWLETT-PACKARD COMPANY DBA HEWLETT-PACKARD CO. OR HP |
| 520/4/00372/000 | K3902 | BAE SYSTEMS MARITIME SERVICES |
| 520/4/00372/000 | U4290 | G E C MARCONI S3I LTD COMBAT SYSTEMS IVISION |
| 521-9248 | 83330 | DIALIGHT CORPORATION |
| 539480-6 | 96214 | RAYTHEON COMPANY DBA RAYTHEON |
| 99130797 | F6481 | THALES SA |
| A3088652-3 | 80063 | US ARMY COMMUNICATIONS & ELECTRONICS MATERIEL READINESS |
| FV05881 | K1090 | SIMOCO EUROPE LTD |
| FV35611 | K1090 | SIMOCO EUROPE LTD |
| HLMP-3401 | 28480 | HEWLETT-PACKARD COMPANY DBA HEWLETT-PACKARD CO. OR HP |
| HLMP-3401 | 50434 | AVAGO TECHNOLOGIES U.S. INC. DIV AVAGO TECHNOLOGIES |
| HLMP-3401 | C1904 | HEWLETT PACKARD GMBH |
| HLMP3401 | K3464 | HEWLETT-PACKARD LTD |
| HP5082-4555 | 50434 | AVAGO TECHNOLOGIES U.S. INC. DIV AVAGO TECHNOLOGIES |
| SC/A4/90179 | K4208 | CHEMRING ENERGETICS UK LIMITED |
