NSN 5977-00-503-9486 S240765341PC48, S2407-65341PC48, 733001
Product Details | ELECTRICAL CONTACT RING ASSEMBLY
5977-00-503-9486 Two or more electrical contact rings on a common mounting or mounted on each other. May include contacts, integral brushes, brush holder assemblies, and connectors.
Part Alternates: S240765341PC48, S2407-65341PC48, 733001, 5977-00-503-9486, 00-503-9486, 5977005039486, 005039486
Electrical and Electronic Equipment Components | Electrical Contact Brushes and Electrodes
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 01 JAN 1963 | 00-503-9486 | 00313 ( RING ASSEMBLY, ELECTRICAL CONTACT ) |
Demand History | NSN 5977-00-503-9486
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 5977-00-503-9486 | 2007-03-69 | 1 | DIBBS |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 5977-00-503-9486
Technical Data | NSN 5977-00-503-9486
| Characteristic | Specifications |
|---|---|
| CONTACT RING QUANTITY | 9 |
| WIDTH | 0.156 INCHES NOMINAL |
| DIAMETER | 11.125 INCHES NOMINAL |
| RING SURFACE MATERIAL | SILVER |
| MOUNTING CONFIGURATION | ONE MTG SLOT 0.188 IN.W BY 0.250 IN. LG LOCATED 27 DEG FROM TERMINALS |
| OVERALL DIAMETER | 11.250 INCHES NOMINAL |
| OVERALL HEIGHT | 2.812 INCHES NOMINAL |
| III FSC APPLICATION DATA | GYRO COMPASS EQUIPMENT |
| MANUFACTURERS CODE | 56232 |
| DESIGN CONTROL REFERENCE | 733001 |
Restrictions/Controls & Freight Information | NSN 5977-00-503-9486
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | S | Item contains silver |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
| Category | Code | Description |
|---|---|---|
| NMF Description | 062120 | GENERATORS/MOTORS/PARTS NOI |
| Less than car load rating | Q | 70 |
| Less than truck load rating | W | Rating Variable |
| Water commodity Code | 593 | unknown |
| Originating Activity Code | XX | |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | H | Signal Corps supplies and equipment, including radio equipment and supplies, communications equipment and supplies, electrical equipment and supplies, etc. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 5977-00-503-9486
Navy| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 9B | Navy-owned stocks of DLA material Naval Inventory Control Point, Mechanicsburg |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Acquisition Advice Codes | Z | INSURANCE/NUMERIC STOCKAGE OBJECTIVE ITEM # Items which may be required occasionally or intermittently, and prudence requires that a nominal quantity of materiel be stocked due to the essentiality or the lead time of the item. 1. The item is centrally managed, stocked, and issued. 2. Requisitions will be submitted in accordance with IMM/Service requisitioning procedures. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 AY : Assembly |
