NSN 5975-01-544-1164 SGXTAPDAT72R2, SG-XTAPDAT72-R-2, 01-544-1164
Product Details | ELECTRONIC JUNCTION RACK
5975-01-544-1164 An open frame structure specifically designed to accommodate (but does not include) electronic terminal junctions (TERMINAL BOARD; TERMINAL (1), FEEDTHRU; and the like). The item may consist of separable or nonseparable channels, mounting blocks and fastening devices. Mounting blocks are designed so the assembly can be mounted on panels or bulkheads. Tightening the fastening devices which secure the channels to the mounting blocks will also secure terminal junctions within the frame assembly. Excludes RACK, ELECTRICAL EQUIPMENT; TERMINAL BOARD; JUNCTION BOX; and HARDWARE KIT, ELECTRONIC EQUIPMENT.
Part Alternates: SGXTAPDAT72R2, SG-XTAPDAT72-R-2, 5975-01-544-1164, 01-544-1164, 5975015441164, 015441164
Electrical and Electronic Equipment Components | Electrical Hardware and Supplies
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 02 OCT 2006 | 01-544-1164 | 32039 ( RACK, ELECTRONIC JUNCTION ) |
Demand History | NSN 5975-01-544-1164
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| SGXTAPDAT72R2 | 2016-08-237 | 6 | us |
| 5975-01-544-1164 | 2012-03-83 | 2 | NATO |
| SG-XTAPDAT72-R-2 | 2012-03-69 | 2 | |
| SG-XTAPDAT72-R-2 | 2011-11-320 | 2 | |
| 5975-01-544-1164 | 2011-11-319 | 2 | NATO |
Cross Reference | NSN 5975-01-544-1164
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| SG-XTAPDAT72-R-2 | 7X430 | SUN MICROSYSTEMS INC. DBA SUN MICROSYSTEMS |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 5975-01-544-1164
Technical Data | NSN 5975-01-544-1164
| Characteristic | Specifications |
|---|---|
| SPECIAL FEATURES | DAT72 TAPE DRIVE; 1U RACKMOUNT ENCLOSURE |
Restrictions/Controls & Freight Information | NSN 5975-01-544-1164
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | P | There is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Electro-static Discharge Susceptible: | A | No known Electrostatic Discharge (ESD) or Electromagnetic Interference (EMI) sensitivity |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
| Category | Code | Description |
|---|---|---|
| NMF Description | 063160 | SWITCH BOXES/ELEC ENCLOSURES |
| Less than car load rating | ||
| Less than truck load rating | W | Rating Variable |
| Water commodity Code | 658 | unknown |
| Originating Activity Code | 80 | NASA Marshall Space Flight Center Marshall Space Flight Center, AL 35812-0001 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | H | Signal Corps supplies and equipment, including radio equipment and supplies, communications equipment and supplies, electrical equipment and supplies, etc. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 5975-01-544-1164
Navy| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 7G | Depot level reparable electronic material to support Naval Inventory Control Point, Space and Naval Warfare Systems Command, Mechanicsburg |
| Special Material Content | 9 | Non-Hazardous or Non-Sensitive Item, does not require hazardous or special handling, packaging or precautions |
| Source of Supply | NRP | NAVICP-ERP 700 Robbins Avenue Philadelphia, PA 19111-5098 |
| Agency | DN | Department of the Navy |
| Service Organization | L | Lead Service - 22 (Repairable) |
| Reparability | H | Depot Level Reparable |
| Acquisition Advice Codes | P | RESTRICTED REQUISITION - SECURITY ASSISTANCE PROGRAM (SAP) 1. Indicates item is stocked or acquired only for SAP (replaces Military Assistance Program (MAP)) requirements, or 2. Indicates item is nonstocked and materiel is ordered from the contractor for shipment directly to the foreign government. 3. Base, post, camp, or station will not requisition. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
