NSN 5975-00-783-8253 45024305, 45024-305, 00-783-8253
Product Details | ELECTRICAL CONDUIT COUPLING NUT
5975-00-783-8253 An item of metallic composition with internal threads and an internal seat designed to join a ferrule capped conduit to a fitting. See also BONDNUT, ELECTRICAL CONDUIT.
Part Alternates: 45024305, 45024-305, 5975-00-783-8253, 00-783-8253, 5975007838253, 007838253
Electrical and Electronic Equipment Components | Electrical Hardware and Supplies
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 01 JAN 1960 | 00-783-8253 | 12814 ( NUT, COUPLING, ELECTRICAL CONDUIT ) |
Drawings & Photos | NSN 5975-00-783-8253
Cross Reference | NSN 5975-00-783-8253
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 45024-305 | 94756 | BOEING COMPANY, THE DBA BOEING |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 5975-00-783-8253
Technical Data | NSN 5975-00-783-8253
| Characteristic | Specifications |
|---|---|
| STYLE DESIGNATOR | A49 KNURLED/RIBBED |
| SEAT END INSIDE DIAMETER | 1.512 INCHES NOMINAL |
| MATERIAL | ALUMINUM |
| SURFACE TREATMENT | ANODIZE |
| THREAD SERIES DESIGNATOR | UNEF SINGLE END |
| NOMINAL THREAD SIZE | 1.500 INCHES SINGLE END |
| THREAD QUANTITY | 18 PER INCH SINGLE END |
| MANUFACTURERS CODE | 94756 |
| DESIGN CONTROL REFERENCE | 45024-305 |
Restrictions/Controls & Freight Information | NSN 5975-00-783-8253
| Category | Code | Description |
|---|---|---|
| Hazardous Material Indicator Code | P | There is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Precious Metals Indicator Code: | U | Precious metal type is unknown |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 013540 | ALUM NUTS |
| Less than car load rating | Q | 70 |
| Less than truck load rating | Q | 70.0 |
| Water commodity Code | 713 | unknown |
| Originating Activity Code | XX | |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | B | Construction materials: Includes paint and related materials, prefabricated building, wood products, metal and composition materials and their products, commercial hardware and miscellaneous items, cement, asphalt, building maintenance materials. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
