NSN 5970-00-788-4901 SCOTCH SUPER 33, SCOTCH33, SCOTCHSUPER33
Product Details | ELECTRICAL INSULATION TAPE
5970-00-788-4901 A narrow strip of woven or processed material less than twelve inches (304.8 mm) in width. It is specifically designed to prevent any undesirable flow of current between conductors and other objects. The item tends to resist any physical change, in contrast to an insulating compound in tape form which will fuse under a specified heat or pressure. It may or may not have adhesive backing. Excludes items not having definite rated electrical characteristics, such as TAPE, ADHESIVE, RUBBER; TAPE, PRESSURE SENSITIVE ADHESIVE; TAPE, SEMI-CONDUCTING, ELECTRICAL; and TAPE, SHIELDING, ELECTRICAL. See also INSULATION CLOTH, ELECTRICAL and INSULATING COMPOUND, ELECTRICAL.
Part Alternates: SCOTCH SUPER 33, SCOTCH33, SCOTCHSUPER33, Q509 19X20, Q50919X20, 7527663-10 , 80610125538, 80-6101-2553-8, 9365986, 3-4452-20-13, 35867026, 35-8670-26 , 3853, 4452, 4452 3/4INWX0.007INTHKX66FTLG, 445234INWX0007INTHKX66FTLG, 15, 15 3/4INWX03007INTHKX66FTLG, 1534INWX03007INTHKX66FTLG, 33PLUS34, 33PLUS3-4, 33T, 7527663 , 5970-00-788-4901, 00-788-4901, 5970007884901, 007884901, 752766310, 344522013
Electrical and Electronic Equipment Components | Electrical Insulators and Insulating Materials
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 01 JAN 1962 | 00-788-4901 | 33476 ( TAPE, INSULATION, ELECTRICAL ) |
Drawings & Photos | NSN 5970-00-788-4901
Demand History | NSN 5970-00-788-4901
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 5970-00-788-4901 | 2024-05-140 | 10157 | DIBBS |
| 5970-00-788-4901 | 2024-04-113 | 3723 | DIBBS |
| 5970-00-788-4901 | 2024-04-105 | 3723 | DIBBS |
| 5970-00-788-4901 | 2024-04-93 | 7 | United States |
| 5970-00-788-4901 | 2024-04-93 | 7 | United States |
| 5970-00-788-4901 | 2023-11-306 | 5106 | DIBBS |
| 33PLUS3-4 | 2022-06-165 | 1152 | United States |
| 5970-00-788-4901 | 2022-06-165 | 1152 | MANUAL |
| 5970-00-788-4901 | 2017-10-276 | 1 | DIBBS-RFPs |
| 4452 | 2012-06-166 | 200 | us |
| 5970-00-788-4901 | 2012-05-144 | 807 | DIBBS |
| 5970-00-788-4901 | 2012-02-47 | 3023 | DIBBS |
| 5970-00-788-4901 | 2012-01-26 | 5897 | DIBBS |
| 5970-00-788-4901 | 2011-09-256 | 5516 | DIBBS |
| 5970-00-788-4901 | 2011-08-213 | 0 | DIBBS |
| 5970-00-788-4901 | 2011-07-188 | 5054 | DIBBS |
| 5970-00-788-4901 | 2011-03-84 | 5529 | DIBBS |
| 5970-00-788-4901 | 2011-03-70 | 4933 | DIBBS |
Cross Reference | NSN 5970-00-788-4901
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 15 | 53387 | 3M COMPANY DIV ELECTRO AND COMMUNICATIONS |
| 15 | 75037 | MINNESOTA MINING AND MFG CO 3M COMPANY |
| 15 3/4INWX03007INTHKX66FTLG | 75037 | MINNESOTA MINING AND MFG CO 3M COMPANY |
| 3-4452-20-13 | 81165 | PLYMOUTH RUBBER CO INC |
| 33PLUS3-4 | 75037 | MINNESOTA MINING AND MFG CO 3M COMPANY |
| 33PLUS3-4 | 76381 | 3M COMPANY DBA 3M |
| 33T | 53387 | 3M COMPANY DIV ELECTRO AND COMMUNICATIONS |
| 3853 | 81165 | PLYMOUTH RUBBER CO INC |
| 4452 | 81165 | PLYMOUTH RUBBER CO INC |
| 4452 3/4INWX0.007INTHKX66FTLG | 81165 | PLYMOUTH RUBBER CO INC |
| 80-6101-2553-8 | D2607 | 3M DEUTSCHLAND GMBH DIV 3M GOVERNMENT SERVICES, EUROPE & |
| 9365986 | 19200 | US ARMY ARDEC RDECOM |
| Q509 19X20 | B0936 | STOKVIS TAPES NV |
| SCOTCH SUPER 33 | 53387 | 3M COMPANY DIV ELECTRO AND COMMUNICATIONS |
| SCOTCH33 | 04963 | 3M COMPANY |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 5970-00-788-4901
Technical Data | NSN 5970-00-788-4901
| Characteristic | Specifications |
|---|---|
| MATERIAL | PLASTIC POLYVINYL CHLORIDE OVERALL |
| COLOR | BLACK OVERALL |
| NOMINAL LENGTH | 792.0 INCHES |
| NOMINAL WIDTH | 0.750 INCHES |
| CUT TYPE AND QUANTITY | 1 SINGLE |
| NOMINAL OVERALL THICKNESS | 0.0070 INCHES |
| ADHESIVE TYPE | PRESSURE SENSITIVE |
| ADHESIVE LOCATION | ONE SIDE |
| TEMP RATING | 105.0 DEG CELSIUS NOMINAL |
| DIELECTRIC WITHSTANDING VOLTAGE IN VOLTS | NOT RATED |
| DIELECTRIC MATERIAL VOLTAGE RATING PER MIL THICKNESS IN VOLTS | 1000.0 |
| DIELECTRIC MATERIAL VOLTAGE RATING PER MILLIMETER THICKNESS IN KILOVOLTS | NOT RATED |
| ENVIRONMENTAL PROTECTION | ACID RESISTANT AND CORROSION RESISTANT AND MOISTURE RESISTANT |
Restrictions/Controls & Freight Information | NSN 5970-00-788-4901
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | P | There is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 052190 | PIPE,TUBING,OR PIPE OR TUBING FITTI |
| Less than car load rating | ||
| Less than truck load rating | W | Rating Variable |
| Water commodity Code | 576 | unknown |
| Originating Activity Code | XX | |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | B | Construction materials: Includes paint and related materials, prefabricated building, wood products, metal and composition materials and their products, commercial hardware and miscellaneous items, cement, asphalt, building maintenance materials. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 5970-00-788-4901
Air Force| Category | Code | Description |
|---|---|---|
| Budget Code | 9 | General Support DIV57X4921.070:Air Force decentrally managed expense items (ERRC XB3, XF-3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors. |
| Materiel Management Aggregation Code | FG | SX:B-52 STRATO FORTRESS |
| Price Validation | N | The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
|
| Fund Code | SF | Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point. |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DF | Department of the Air Force |
| Service Organization | F | U.S. Air Force |
| Reparability | N | Stock Fund (except Munitions) |
| Acquisition Advice Codes | Z | INSURANCE/NUMERIC STOCKAGE OBJECTIVE ITEM # Items which may be required occasionally or intermittently, and prudence requires that a nominal quantity of materiel be stocked due to the essentiality or the lead time of the item. 1. The item is centrally managed, stocked, and issued. 2. Requisitions will be submitted in accordance with IMM/Service requisitioning procedures. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
