NSN 5962-01-117-2595 SMC8007531, SM-C-800753-1 , GEM11821BEA
Product Details | DIGITAL MICROCIRCUIT
5962-01-117-2595 A microcircuit specifically designed to generate, modify, or process electrical signals which operate with two distinct or binary states. These states are commonly referred to as on and off, true and false, high and low, or "1" and "0".
Part Alternates: SMC8007531, SM-C-800753-1 , GEM11821BEA , 333ML902, 333ML-902, 333ML902X, 333ML902XA, 5670762, 567076-2, 5962-01-117-2595, 01-117-2595, 5962011172595, 011172595
Electrical and Electronic Equipment Components | Microcircuits, Electronic
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 12 AUG 1981 | 01-117-2595 | 31779 ( MICROCIRCUIT, DIGITAL ) |
Drawings & Photos | NSN 5962-01-117-2595
Demand History | NSN 5962-01-117-2595
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 5962-01-117-2595 | 2016-03-64 | 20 | United States |
| 5962-01-117-2595 | 2012-09-261 | 7 | South Korea |
| 333ML902X | 2012-04-100 | 7 | South Korea |
| 5962-01-117-2595 | 2012-04-100 | 7 | MANUAL |
| 5962-01-117-2595 | 2012-02-32 | 7 | US |
| 5962-01-117-2595 | 2011-01-13 | 10 | CN |
| 5962-01-117-2595 | 2010-03-84 | 81 | DIBBS |
Cross Reference | NSN 5962-01-117-2595
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 333ML-902 | 06481 | NORTHROP GRUMMAN SYSTEMS CORPORATION |
| 333ML902 | 15818 | TELCOM SEMICONDUCTOR INC |
| 333ML902X | 15818 | TELCOM SEMICONDUCTOR INC |
| 333ML902X | C7191 | ADELCO ELEKTRONIK GMBH |
| 333ML902XA | C7191 | ADELCO ELEKTRONIK GMBH |
| 567076-2 | 49956 | RAYTHEON COMPANY DBA RAYTHEON |
| GEM11821BEA | 0DKS7 | SRI INTERNATIONAL |
| SM-C-800753-1 | 0DKS7 | SRI INTERNATIONAL |
| SM-C-800753-1 | 80063 | US ARMY COMMUNICATIONS & ELECTRONICS MATERIEL READINESS |
