NSN 5961-01-584-5337 2N4416A, 6014209001, 6014209-001
Product Details | TRANSISTOR
5961-01-584-5337 An active semiconductor device with three or more electrodes. May or may not include mounting hardware and/or heatsink. Excludes SEMICONDUCTOR DEVICE, DIODE and SEMICONDUCTOR DEVICE, THYRISTOR. For solid state devices which are responsive to visible or infrared radiant energy, see SEMICONDUCTOR DEVICE, PHOTO.
Part Alternates: 2N4416A, 6014209001, 6014209-001, 6102N4416A, 610-2N4416A , 5961-01-584-5337, 01-584-5337, 5961015845337, 015845337
Electrical and Electronic Equipment Components | Semiconductor Devices and Associated Hardware
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 28 APR 2010 | 01-584-5337 | 20588 ( TRANSISTOR ) |
Drawings & Photos | NSN 5961-01-584-5337
Demand History | NSN 5961-01-584-5337
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 6014209-001 | 2024-09-267 | 185 | DIBBS |
| 610-2N4416A | 2024-09-267 | 185 | DIBBS |
| 6014209-001 | 2024-09-256 | 185 | DIBBS |
| 610-2N4416A | 2024-09-256 | 185 | DIBBS |
| 6014209-001 | 2024-02-39 | 230 | DIBBS |
| 610-2N4416A | 2024-02-39 | 230 | DIBBS |
| 5961-01-584-5337 | 2017-04-108 | 1 | DIBBS-RFPs |
| 2N4416A | 2016-12-344 | 4 | United States |
| 5961-01-584-5337 | 2015-07-186 | 86 | DIBBS |
| 5961-01-584-5337 | 2015-05-138 | 2 | DIBBS |
| 5961-01-584-5337 | 2015-05-125 | 2 | DIBBS |
| 5961-01-584-5337 | 2015-03-76 | 1 | DIBBS |
| 5961-01-584-5337 | 2014-11-311 | 2 | DIBBS |
| 5961-01-584-5337 | 2014-10-294 | 2 | DIBBS |
| 5961-01-584-5337 | 2012-09-247 | 6 | DIBBS |
| 6014209001 | 2008-11-317 | 1 | Malaysia |
