NSN 5961-01-146-7710 MA7700K0105, MA7700K-0105, ACTP1582P

Product Details | DIODE SEMICONDUCTOR DEVICE

5961-01-146-7710 A two electrode semiconductor device having an asymmetrical voltage - current characteristic. May or may not include mounting hardware and/or heatsink. Excludes LIGHT EMITTING DIODE and SEMICONDUCTOR DEVICE,PHOTO. For items containing material such as selenium and copper oxide, see RECIFIER, METALLIC.

Part Alternates: MA7700K0105, MA7700K-0105, ACTP1582P, ACTP-1582P, ACTP1582PC6, ACTP-1582PC6 , 583R263H02, 5961-01-146-7710, 01-146-7710, 5961011467710, 011467710

Electrical and Electronic Equipment Components | Semiconductor Devices and Associated Hardware

Supply Group (FSG)	NSN Assign.	NIIN	Item Name Code (INC)
59	04 FEB 1983	01-146-7710	20589 ( SEMICONDUCTOR DEVICE, DIODE )

Drawings & Photos | NSN 5961-01-146-7710

Part Number	Request Date	QTY	Origin
583R263H02	2022-09-249	8	United States
583R263H02	2022-08-227	10	United States
583R263H02	2019-02-38	5	United States
5961-01-146-7710	2015-02-33	9	DIBBS
5961-01-146-7710	2014-08-217	5	DIBBS
5961-01-146-7710	2013-05-139	8	DIBBS
5961-01-146-7710	2013-03-88	4	DIBBS
5961-01-146-7710	2013-02-37	2	TW
5961-01-146-7710	2012-11-309	11	DIBBS
5961-01-146-7710	2012-09-245	9	DIBBS
5961-01-146-7710	2011-11-320	2	United States
583R263H02	2011-11-319	2	United States

Cross Reference | NSN 5961-01-146-7710

Part Number	Cage Code	Manufacturer
583R263H02	14844	FREQUENCY ELECTRONICS, INC. DIV FREQUENCY ELECTRONICS, INC.
583R263H02	21847	FEI MICROWAVE INC
583R263H02	97942	NORTHROP GRUMMAN SYSTEMS CORPORATION DIV NORTHROP GRUMMAN SYSTEMS
ACTP-1582P	62482	AEROFLEX CONTROL COMPONENTS, INC DBA ADVANCE CONTROL COMPONENTS
ACTP-1582PC6	64537	AEROFLEX CONTROL COMPONENTS, INC. DBA AEROFLEX / KDI
MA7700K-0105	96341	COBHAM ELECTRONIC SYSTEMS INC. DBA COBHAM DEFENSE ELECTRONICS

Request a Quote

What Our Customers Say

Thank you very much for the excellent service and professional customer care.

Ernie G. Honeywell

The service was excellent. I can think of no improvements to date that you can make regarding internet sales.

John L. Raytheon

The representative for WBParts was efficient & handled our request in a timely & professional manner.

Karen G. General Dynamics

Tried two other sources, neither of them responded, was all done online, never spoke to anyone.

Rex S. US Airforce

The response is quick and the price is often very good. We are completely satisfied.

Patricia S. NASA

Compare

NSNs for Compare ( up to 4 ): Add 5961-01-146-7710

Compare

Related Products | NSN 5961-01-146-7710

5961-01-146-7851, 5961-01-146-7852, 5961-01-146-7853, 5961-01-146-7854, 5961-01-146-7855

Technical Data | NSN 5961-01-146-7710

Characteristic	Specifications
INCLOSURE MATERIAL	METAL
OVERALL LENGTH	2.050 INCHES NOMINAL
OVERALL DIAMETER	0.340 INCHES NOMINAL
FUNCTION FOR WHICH DESIGNED	TUNNEL DIODE
MANUFACTURERS CODE	97942
DESIGN CONTROL REFERENCE	583R263H02

Restrictions/Controls & Freight Information | NSN 5961-01-146-7710

Restrictions
Freight

Category	Code	Description
Shelf-Life Code:	0	Nondeteriorative
Hazardous Material Indicator Code	N	There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials
Demilitarization Code:	A	Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required.
Controlled Inventory Item Code:	U	UNCLASSIFIED
Electro-static Discharge Susceptible:	B	ESD sensitivity
Precious Metals Indicator Code:	A	Item does not contain precious metal
Criticality Code:	X	The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application.
Automatic Data Processing Equipment:	0	Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9)

Category	Code	Description
NMF Description	063025	SEMICONDUCTORS/DEVICES NOI ETC
Less than car load rating
Less than truck load rating	W	Rating Variable
Water commodity Code	72D	unknown
Originating Activity Code	BF	U.S. Army Armament and Chemical Acquisition and Logistics Activity Rock Island, IL 61299-6000
Air Dimension Code	A	Shipment is not a consolidation and does not exceed 72 inches in any dimension.
Air Commodity	H	Signal Corps supplies and equipment, including radio equipment and supplies, communications equipment and supplies, electrical equipment and supplies, etc.
Air Special Handling	Z	No special handling required.
Special Handling Code	9	unknonwn
HAZMAT
