NSN 5961-00-457-9123 JANTXV1N968B, MIL-PRF-19500/117, MILPRF19500117
Product Details | DIODE SEMICONDUCTOR DEVICE
5961-00-457-9123 A two electrode semiconductor device having an asymmetrical voltage - current characteristic. May or may not include mounting hardware and/or heatsink. Excludes LIGHT EMITTING DIODE and SEMICONDUCTOR DEVICE,PHOTO. For items containing material such as selenium and copper oxide, see RECIFIER, METALLIC.
Part Alternates: JANTXV1N968B, MIL-PRF-19500/117, MILPRF19500117, MIL-S-19500/117, MILS19500117, 111B00273, 111-B-0027-3 , 111B0027-3 , 5961-00-457-9123, 00-457-9123, 5961004579123, 004579123
Electrical and Electronic Equipment Components | Semiconductor Devices and Associated Hardware
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 03 JUN 1974 | 00-457-9123 | 20589 ( SEMICONDUCTOR DEVICE, DIODE ) |
Drawings & Photos | NSN 5961-00-457-9123
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 5961-00-457-9123
Related Products | NSN 5961-00-457-9123
Technical Data | NSN 5961-00-457-9123
| Characteristic | Specifications |
|---|---|
| SEMICONDUCTOR MATERIAL | SILICON |
| VOLTAGE RATING IN VOLTS PER CHARACTERISTIC | 19.0 MAXIMUM NOMINAL REGULATOR VOLTAGE |
| CURRENT RATING PER CHARACTERISTIC | 19.00 MILLIAMPERES MAXIMUM VOLTAGE REGULATOR DIODE CURRENT |
| POWER RATING PER CHARACTERISTIC | 400.0 MILLIWATTS MAXIMUM TOTAL POWER DISSIPATION |
| MAXIMUM OPERATING TEMP PER MEASUREMENT POINT | 175.0 DEG CELSIUS AMBIENT AIR |
| INCLOSURE MATERIAL | GLASS |
| MOUNTING METHOD | TERMINAL |
| TERMINAL LENGTH | 1.000 INCHES MINIMUM AND 1.500 INCHES MAXIMUM |
| TERMINAL TYPE AND QUANTITY | 2 UNINSULATED WIRE LEAD |
| OVERALL LENGTH | 0.230 INCHES MINIMUM AND 0.300 INCHES MAXIMUM |
| OVERALL DIAMETER | 0.085 INCHES MINIMUM AND 0.130 INCHES MAXIMUM |
| FEATURES PROVIDED | HERMETICALLY SEALED CASE |
| TEST DATA DOCUMENT | 81349-MIL-S-19500 SPECIFICATION |
| (NON-CORE DATA) SPECIFICATION/STANDARD DATA | 81349-MIL-S-19500/117 GOVERNMENT SPECIFICATION |
| MANUFACTURERS CODE | 81349 |
| DEFINITIVE GOVERNMENT SPEC/STD REFERENCE | JANTXV1N968B |
| MANUFACTURERS CODE | 81349 |
| NON-DEFINITIVE GOVERNMENT SPEC/STD REFERENCE | MIL-PRF-19500/117 |
