NSN 5961-00-103-6748 A433841, A43384-1, SRF518
Product Details | TRANSISTOR
5961-00-103-6748 An active semiconductor device with three or more electrodes. May or may not include mounting hardware and/or heatsink. Excludes SEMICONDUCTOR DEVICE, DIODE and SEMICONDUCTOR DEVICE, THYRISTOR. For solid state devices which are responsive to visible or infrared radiant energy, see SEMICONDUCTOR DEVICE, PHOTO.
Part Alternates: A433841, A43384-1, SRF518, K2127, A485, 151-0212-00, 82101194, 8210-1194, 5961-00-103-6748, 00-103-6748, 5961001036748, 151021200, 001036748
Electrical and Electronic Equipment Components | Semiconductor Devices and Associated Hardware
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 19 JUN 1968 | 00-103-6748 | 20588 ( TRANSISTOR ) |
Drawings & Photos | NSN 5961-00-103-6748
Demand History | NSN 5961-00-103-6748
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| A485 | 2021-08-229 | 150 | United States |
| A485 | 2020-09-272 | 600 | United States |
| A485 | 2019-10-280 | 600 | United States |
| A485 | 2019-10-277 | 600 | United States |
| A485 | 2019-09-252 | 600 | United States |
| A485 | 2019-09-252 | 600 | United States |
| A485 | 2019-06-176 | 600 | United States |
| A485 | 2018-10-282 | 2000 | United States |
| A485 | 2018-09-260 | 1000 | United States |
| A485 | 2018-09-260 | 1000 | United States |
| 5961-00-103-6748 | 2018-03-84 | 491 | DIBBS |
Cross Reference | NSN 5961-00-103-6748
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 151-0212-00 | 80009 | TEKTRONIX, INC. DBA TEKTRONIX |
| 8210-1194 | 24655 | GENRAD INC |
| 8210-1194 | 62015 | IET LABS., INC. DBA IET LABS |
| A43384-1 | 42498 | DAR ELECTRONICS INC DBA NATIONAL RADIO CO |
| A485 | 25403 | PHILIPS CIRCUIT ASSEMBLIES |
| A485 | 73445 | AMPEREX ELECTRONIC CORP |
| K2127 | 96341 | COBHAM ELECTRONIC SYSTEMS INC. DBA COBHAM DEFENSE ELECTRONICS |
| K2127 | DG438 | SEMIC RF ELECTRONIC GMBH |
| SRF518 | 04713 | FREESCALE SEMICONDUCTOR, INC. |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 5961-00-103-6748
Related Products | NSN 5961-00-103-6748
Technical Data | NSN 5961-00-103-6748
| Characteristic | Specifications |
|---|---|
| SEMICONDUCTOR MATERIAL | SILICON |
| INTERNAL CONFIGURATION | JUNCTION CONTACT |
| VOLTAGE RATING IN VOLTS PER CHARACTERISTIC | 30.0 MAXIMUM BREAKDOWN VOLTAGE, COLLECTOR-TO-BASE, EMITTER OPEN AND 12.0 MAXIMUM BREAKDOWN VOLTAGE, COLLECTOR-TO-EMITTER, BASE OPEN AND 2.0 MAXIMUM BREAKDOWN VOLTAGE, EMITTER-TO-BASE, COLLECTOR OPEN |
| POWER RATING PER CHARACTERISTIC | 0.2 WATTS MAXIMUM COLLECTOR POWER DISSIPATION |
| MAXIMUM OPERATING TEMP PER MEASUREMENT POINT | 200.0 DEG CELSIUS JUNCTION |
| INCLOSURE MATERIAL | METAL |
| MOUNTING METHOD | TERMINAL |
| TERMINAL LENGTH | 0.500 INCHES MINIMUM |
| TERMINAL CIRCLE DIAMETER | 0.100 INCHES NOMINAL |
| TERMINAL TYPE AND QUANTITY | 4 UNINSULATED WIRE LEAD |
| OVERALL LENGTH | 0.210 INCHES MAXIMUM |
| OVERALL DIAMETER | 0.230 INCHES MAXIMUM |
| FEATURES PROVIDED | HERMETICALLY SEALED CASE |
| SPECIAL FEATURES | JUNCTION PATTERN ARRANGEMENT: NPN |
| MANUFACTURERS CODE | 42498 |
| MFR SOURCE CONTROLLING REFERENCE | A43384-1 |
