NSN 5950-01-136-1946 TP892, 88ES128, 1424711
Product Details | PULSE TRANSFORMER
5950-01-136-1946 A transformer designed to transfer pulses of nonsinusoidal wave forms between circuits without basically changing the wave forms.
Part Alternates: TP892, 88ES128, 1424711, 142471-1, 5950-01-136-1946, 01-136-1946, 5950011361946, 011361946
Electrical and Electronic Equipment Components | Coils and Transformers
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 04 AUG 1982 | 01-136-1946 | 00208 ( TRANSFORMER, PULSE ) |
Demand History | NSN 5950-01-136-1946
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 1424711 | 2011-07-210 | 3 | US |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 5950-01-136-1946
Related Products | NSN 5950-01-136-1946
Technical Data | NSN 5950-01-136-1946
| Characteristic | Specifications |
|---|---|
| TERMINAL TYPE AND QUANTITY | 6 STANDOFF, THREADED STUD |
| WINDING OPERATING CURRENT | 6.8 AMPERES DC MAXIMUM SINGLE COMPONENT SINGLE PRIMARY |
| DC RESISTANCE RATING IN OHMS | 0.800 SINGLE COMPONENT 1ST SECONDARY |
| PRIMARY TO SECONDARY TURN RATIO | 1 TO 9-1/4 SINGLE COMPONENT |
| (NON-CORE DATA) PULSE DURATION IN MICROSECONDS | 0.310 SINGLE COMPONENT |
| (NON-CORE DATA) PULSE RISE TIME IN MICROSECONDS | 0.085 SINGLE COMPONENT |
| (NON-CORE DATA) PULSE DECAY TIME IN MICROSECONDS | 0.150 SINGLE COMPONENT |
| PULSE REPETITION RATE | 6.0 KILOHERTZ SINGLE COMPONENT |
| WINDING SHIELDING METHOD | CORE GROUNDED TO INCLOSURE SINGLE COMPONENT |
| WINDING FUNCTION AND QUANTITY | 1 PRIMARY AND 2 SECONDARY SINGLE COMPONENT |
| MOUNTING METHOD | UNTHREADED HOLE SINGLE GROUP |
| MOUNTING FACILITY QUANTITY | 6 SINGLE GROUP |
| MOUNTING HOLE DIAMETER | 0.250 INCHES NOMINAL SINGLE GROUP |
| CENTER TO CENTER DISTANCE BETWEEN MOUNTING FACILITIES PARALLEL TO LENGTH | 10.740 INCHES MINIMUM AND 10.760 INCHES MAXIMUM SINGLE MOUNTING FACILITY SINGLE CENTER GROUP |
| CENTER TO CENTER DISTANCE BETWEEN MOUNTING FACILITIES PARALLEL TO WIDTH | 7.970 INCHES MINIMUM AND 8.030 INCHES MAXIMUM SINGLE MOUNTING FACILITY SINGLE CENTER GROUP |
| INCLOSURE TYPE | HERMETICALLY SEALED |
| BODY LENGTH | 11.720 INCHES MINIMUM AND 11.780 INCHES MAXIMUM |
| BODY HEIGHT | 5.970 INCHES MINIMUM AND 6.030 INCHES MAXIMUM |
| BODY WIDTH | 8.970 INCHES MINIMUM AND 9.030 INCHES MAXIMUM |
| RELIABILITY INDICATOR | NOT ESTABLISHED |
| III MAXIMUM OPERATING TEMP | 130.0 DEG CELSIUS |
| (NON-CORE DATA) UNPACKAGED UNIT WEIGHT | 44.000 POUNDS |
| (NON-CORE DATA) CUBIC MEASURE | 641.4 CUBIC INCHES |
Restrictions/Controls & Freight Information | NSN 5950-01-136-1946
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | Y | Information is in the Hazardous Materials Information System (HMIS) |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 063420 | TRANSFORMERS,NOI,OR TRANSFORMER PAR |
| Less than car load rating | ||
| Less than truck load rating | W | Rating Variable |
| Water commodity Code | 595 | unknown |
| Originating Activity Code | TX | Defense Supply Center Columbus Columbus, OH 43218 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | H | Signal Corps supplies and equipment, including radio equipment and supplies, communications equipment and supplies, electrical equipment and supplies, etc. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 5950-01-136-1946
Navy| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 9B | Navy-owned stocks of DLA material Naval Inventory Control Point, Mechanicsburg |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Acquisition Advice Codes | J | NOT STOCKED, CENTRALLY PROCURED # (NON-STOCKED ITEMS) IMM/Service centrally managed but not stocked item. Procurement will be initiated only after receipt of a requisition. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
