Product Details | VIBRATOR POWER TRANSFORMER
5950-00-809-9388 A transformer consisting of two or more windings designed for use with a vibrator for stepping up or down pulsating direct current voltages. May also have provisions for alternating current input voltages. Excludes TRANSFORMER, PULSE.
Part Alternates: T101885, 11040758-1, 5950-00-809-9388, 00-809-9388, 5950008099388, 110407581, 008099388
Electrical and Electronic Equipment Components | Coils and Transformers
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 01 JUL 1968 | 00-809-9388 | 00784 ( TRANSFORMER, POWER, VIBRATOR ) |
Drawings & Photos | NSN 5950-00-809-9388
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 5950-00-809-9388
Technical Data | NSN 5950-00-809-9388
| Characteristic | Specifications |
|---|---|
| TERMINAL TYPE AND QUANTITY | 12 PIN |
| (NON-CORE DATA) WINDING TAP LOCATION | CENTER TAP SINGLE COMPONENT ALL PRIMARY CENTER TAP SINGLE COMPONENT ALL SECONDARY |
| WINDING OPERATING VOLTAGE | 10.00 DC VOLTS NOMINAL SINGLE COMPONENT 1ST PRIMARY |
| WINDING FUNCTION AND QUANTITY | 2 PRIMARY AND 2 SECONDARY SINGLE COMPONENT |
| MOUNTING METHOD | TERMINAL SINGLE GROUP |
| MOUNTING BOLT CIRCLE DIAMETER | 0.750 INCHES NOMINAL SINGLE MOUNTING FACILITY SINGLE CENTER GROUP |
| INCLOSURE TYPE | FULLY INCLOSED |
| OVERALL DIAMETER | 1.250 INCHES NOMINAL |
| OVERALL HEIGHT | 0.791 INCHES NOMINAL |
| RELIABILITY INDICATOR | NOT ESTABLISHED |
