Product Details | ELECTROMAGNETIC COMPONENT CORE
5950-00-784-9353 A solid or assembled item made of ferromagnetic material and designed to be used for the construction of a COIL (as modified), a TRANSFORMER (as modified), a REACTOR (as modified) or a ELECTROMAGNET. the item increases the magnetic flux within those components.
Part Alternates: 20645400003, 2064540-0003, 5950-00-784-9353, 00-784-9353, 5950007849353, 007849353
Electrical and Electronic Equipment Components | Coils and Transformers
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 01 JAN 1960 | 00-784-9353 | 52210 ( CORE, ELECTROMAGNETIC COMPONENT ) |
Cross Reference | NSN 5950-00-784-9353
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 2064540-0003 | 27914 | HONEYWELL INTERNATIONAL INC DBA HONEYWELL |
