NSN 5945-01-023-1668 LO2086, 4A39B, 4AS39B
Product Details | ROTARY RELAY
5945-01-023-1668 A relay whose contact arm may rotate through 360 degrees but not in one operation. Includes rotary relays which automatically reset. For an item having the dual functions of a switch and a relay assembled together on a common mounting, see RELAY-SWITCH. Excludes SWITCH, ROTARY; SWITCH, STEPPING; and SWITCH, TELEPHONE (as modified).
Part Alternates: LO2086, 4A39B, 4AS39B, 4AS39-B, 4AX1624, 4A-X1624, 5945-01-023-1668, 01-023-1668, 5945010231668, 010231668
Electrical and Electronic Equipment Components | Relays and Solenoids
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 12 JUN 1976 | 01-023-1668 | 03890 ( RELAY, ROTARY ) |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 5945-01-023-1668
Technical Data | NSN 5945-01-023-1668
| Characteristic | Specifications |
|---|---|
| STRUCTURAL DESIGN | NONPILE-UP |
| CONTACT ARRANGEMENT | 4PDT |
| CONTACT CURRENT TYPE | AC AND DC |
| CONTACT MAXIMUM VOLTAGE RATING IN VOLTS | 120.0 |
| CONTACT CURRENT RATING AT MAXIMUM RATED VOLTAGE | 1.0 AMPERES RESISTIVE |
| CONTACT MAXIMUM RATED CURRENT | 5.0 AMPERES RESISTIVE |
| CONTACT VOLTAGE RATING AT MAXIMUM RATED CURRENT | 30.0 |
| COIL WINDING QUANTITY | 1 |
| WINDING CHARACTERISTIC | SINGLE WOUND UNTAPPED |
| DC OPERATING VOLTAGE RATING IN VOLTS | 53.0 NOMINAL |
| PULL-IN CURRENT | 21.0 MILLIAMPERES MAXIMUM |
| COIL DC RESISTANCE | 1.14 KILOHMS NOMINAL |
| COIL TERMINAL QUANTITY | 2 |
| CONTACT TERMINAL QUANTITY | 12 |
| SHAFT ROTATION IN DEG | 30.0 |
| RESET FACILITY FEATURE | NOT PROVIDED |
| ENVIRONMENTAL PROTECTION | HERMETICALLY SEALED |
| OVERALL HEIGHT | 1.750 INCHES NOMINAL |
| OVERALL LENGTH | 1.719 INCHES NOMINAL |
| OVERALL WIDTH | 1.188 INCHES NOMINAL |
| MOUNTING CONFIGURATION | TWO 0.156 IN. DIA MTG HOLES SPACED 1.437 IN. C TO C |
| SPECIAL FEATURES | ITEM MUST COMPLY WITH REQUIREMENTS OF DEFENSE SUPPLY CENTER COLUMBUS PRODUCTION STANDARD NO. LO2086 |
| REFERENCE NUMBER DIFFERENTIATING CHARACTERISTICS | REFERENCE NUMBER DIFFERENTIATING MATERIAL WILL BE IN ACCORDANCE WITH NAVAL INVENTORY CONTROL POINT ACTIVITY HX QUALITY CONTROL. MANUFACTURING AND TESTING SPECIFICATIONS AVAILABLE AT THE DLA ICP |
| CRITICALITY CODE JUSTIFICATION | FEAT |
| MANUFACTURERS CODE | 99699 |
| DESIGN CONTROL REFERENCE | 4AS39-B |
Restrictions/Controls & Freight Information | NSN 5945-01-023-1668
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | U | Precious metal type is unknown |
| Criticality Code: | S | The item is a non-aviation Critical Safety Item (CSI) whose failure will result in serious damage to equipment or serious injury or death to personnel. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 061300 | CIRCUIT BREAKER/SWITCH NOI |
| Less than car load rating | ||
| Less than truck load rating | P | 77.5 |
| Water commodity Code | 658 | unknown |
| Originating Activity Code | TX | Defense Supply Center Columbus Columbus, OH 43218 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | H | Signal Corps supplies and equipment, including radio equipment and supplies, communications equipment and supplies, electrical equipment and supplies, etc. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 5945-01-023-1668
Navy| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 9B | Navy-owned stocks of DLA material Naval Inventory Control Point, Mechanicsburg |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Acquisition Advice Codes | Z | INSURANCE/NUMERIC STOCKAGE OBJECTIVE ITEM # Items which may be required occasionally or intermittently, and prudence requires that a nominal quantity of materiel be stocked due to the essentiality or the lead time of the item. 1. The item is centrally managed, stocked, and issued. 2. Requisitions will be submitted in accordance with IMM/Service requisitioning procedures. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
