NSN 5945-00-846-5794 MK3EPUADC12V, MK3EP-UA-DC12V, MKH3D12
Product Details | ELECTROMAGNETIC RELAY
5945-00-846-5794 A relay which is actuated by the effect of a magnetic field developed by the current in its energizing coil(s). Includes solenoid and armature types. Excludes CONTACTOR, MAGNETIC; RELAY, METER MOVEMENT; RELAY, MOTOR DRIVEN; RELAY, REED; RELAY, RESONANT REED; RELAY, ROTARY; and SWITCH, STEPPING.
Part Alternates: MK3EPUADC12V, MK3EP-UA-DC12V, MKH3D12, CAD14D10/12 , CAD14D1012, KRP14DG, KRP14DG12, KRP14DG12D, KRP14DG-12-D, KRP14DG12V, KRPA14DG, KRPA14DG12, KRPA-14-DG-12 , KRPA14DG-12, W250CPX10, W250CPX-10, 100588-001 , 3126828112, 31-268281-12, 314XCX48P12VDC, 4205401, 420540-1, 43N4114, 43N4-114, 0008004097, 000-8004-097, 6552245, 8-1393104-2 , 5945-00-846-5794, 00-846-5794, 5945008465794, 100588001, 008465794, 813931042
Electrical and Electronic Equipment Components | Relays and Solenoids
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 01 JAN 1962 | 00-846-5794 | 32512 ( RELAY, ELECTROMAGNETIC ) |
Drawings & Photos | NSN 5945-00-846-5794
Demand History | NSN 5945-00-846-5794
