NSN 5945-00-632-0634 0802023201, 080-20232-01, 20232A
Product Details | THERMAL FLASHER
5945-00-632-0634 An item designed to complete, interrupt or change the connections in one or more electrical lighting circuits in accordance with a predetermined time cycle. It is actuated by the effect of heat generated by current passing through its circuit(s). Excludes CONTROL, DIRECTIONAL SIGNAL LIGHT, AUTOMOTIVE, and SWITCH THERMOSTATIC. See also FLASHER, SOLID STATE.
Part Alternates: 0802023201, 080-20232-01, 20232A, 673189-105, 5945-00-632-0634, 00-632-0634, 5945006320634, 006320634, 673189105
Electrical and Electronic Equipment Components | Relays and Solenoids
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 21 MAR 1975 | 00-632-0634 | 08410 ( FLASHER, THERMAL ) |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 5945-00-632-0634
Technical Data | NSN 5945-00-632-0634
| Characteristic | Specifications |
|---|---|
| ADJUSTABILITY | NONADJUSTABLE |
| FLASHING RATE | 3 PER SECOND MINIMUM AND 5 PER SECOND MAXIMUM |
| CONTROLLED CIRCUIT QUANTITY | 14 |
| ACTUATION TYPE | THERMAL |
| DC VOLTAGE RATING | 28.0 VOLTS NOMINAL |
| BATTERY OPERATION FACILITY | NOT PROVIDED |
| TERMINAL QUANTITY | 1 |
| TERMINAL TYPE | CONNECTOR, RECEPTACLE |
| LAMP QUANTITY FOR WHICH DESIGNED | 14 |
| LAMP POWER RATING FOR WHICH DESIGNED | 0.500 AMPERES MINIMUM AND 1.000 AMPERES MAXIMUM |
| OPERATING MECHANISM INCLOSURE | NOT INCLUDED |
| ENVIRONMENTAL PROTECTION | VIBRATION PROOF |
| OVERALL LENGTH | 5.500 INCHES MAXIMUM |
| OVERALL HEIGHT | 3.100 INCHES NOMINAL |
| OVERALL WIDTH | 4.000 INCHES MAXIMUM |
| MOUNTING CONFIGURATION | 4 MTG HOLES 0.223 IN. DIA ON 4.500 IN. BY 3.500 IN. MTG CENTERS |
| III CUBIC MEASURE | 68.200 CUBIC INCHES |
| III UNPACKAGED UNIT WEIGHT | 2.300 POUNDS |
Restrictions/Controls & Freight Information | NSN 5945-00-632-0634
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 061300 | CIRCUIT BREAKER/SWITCH NOI |
| Less than car load rating | ||
| Less than truck load rating | P | 77.5 |
| Water commodity Code | 658 | unknown |
| Originating Activity Code | KE | Naval ICP Philadelphia, PA 19111 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | H | Signal Corps supplies and equipment, including radio equipment and supplies, communications equipment and supplies, electrical equipment and supplies, etc. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 5945-00-632-0634
Navy| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 9B | Navy-owned stocks of DLA material Naval Inventory Control Point, Mechanicsburg |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Acquisition Advice Codes | J | NOT STOCKED, CENTRALLY PROCURED # (NON-STOCKED ITEMS) IMM/Service centrally managed but not stocked item. Procurement will be initiated only after receipt of a requisition. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
