5945-00-480-8077 A relay whose contact arm may rotate through 360 degrees but not in one operation. Includes rotary relays which automatically reset. For an item having the dual functions of a switch and a relay assembled together on a common mounting, see RELAY-SWITCH. Excludes SWITCH, ROTARY; SWITCH, STEPPING; and SWITCH, TELEPHONE (as modified).

Part Alternates: MDR1351, MDR135-1, MDR1351V1A, MDR135-1V1A, L876N1B24718REVAITEMNO43, 913684PC12, 231B233CDPC4, 5945-00-480-8077, 00-480-8077, 5945004808077, 004808077

Electrical and Electronic Equipment Components | Relays and Solenoids

Supply Group (FSG) NSN Assign. NIIN
59 16 SEP 1970 00-480-8077

Drawings & Photos | NSN 5945-00-480-8077


Demand History | NSN 5945-00-480-8077

Part Number Request Date QTY Origin
MDR1351 2018-03-61 1 United States
5945-00-480-8077 2010-06-154 2 United States
5945-00-480-8077 2009-03-75 1 US
MDR1351 2009-03-75 1 US
MDR1351 2007-07-206 8 US
MDR1351 2007-07-199 8 Israel

Cross Reference | NSN 5945-00-480-8077

Part Number Cage Code Manufacturer
231B233CDPC4 02989 GENERAL ELECTRIC CO GE DRIVE SYSTEMS
913684PC12 0AHP5 CURTISS-WRIGHT CONTROLS, INC DIV FLIGHT SYSTEMS
L876N1:B24718 REV A, ITEM NO.43 74924 INDUSTRIAL ENGINEERING AND EQUIPMENT COMPANY, INCORPORATED
MDR135-1 77342 TYCO ELECTRONICS CORPORATION
MDR135-1 81349 MILITARY SPECIFICATIONS PROMULGATED BY MILITARY
MDR135-1V1A 77342 TYCO ELECTRONICS CORPORATION

Request a Quote

What Our Customers Say

Compare

NSNs for Compare ( up to 4 ): Add 5945-00-480-8077

Technical Data | NSN 5945-00-480-8077

Characteristic Specifications
REFERENCE NUMBER DIFFERENTIATING CHARACTERISTICS MATERIAL WILL BE IN ACCORDANCE WITH NAVICP MECH; ACTIVITY HX QUALITY CONTROL, MANUFACTURING AND TESTING SPECIFICATIONS.
CRITICALITY CODE JUSTIFICATION ZZZY
MANUFACTURERS CODE 77342
DESIGN CONTROL REFERENCE MDR135-1

Restrictions/Controls & Freight Information | NSN 5945-00-480-8077

Category Code Description
Shelf-Life Code:0Nondeteriorative
Hazardous Material Indicator CodeNThere is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials
Demilitarization Code:FMunitions List Item or Commerce Control List Item. Demilitarization required. Demilitarization Instructions to be furnished by the Item/Technical Manager.
Controlled Inventory Item Code:7NON-SENSITIVE (SRC-N/A) - UNCLASSIFIED AA&E: OR ITEMS ASSIGNED A DEMILITARIZATION CODE OTHER THAN A, B, Q, OR P FOR WHICH ANOTHER CIIC IS INAPPROPRIATE. (NOTE: THE LOSS, THEFT, UNLAWFUL DISPOSITION, AND/OR RECOVERY OF AN ITEM WITH CIIC 7 WILL BE INVESTIGATED IN ACCORDANCE WITH DOD-4000-25-2-M AND DOD 7200.14-R, VOLUME 12, CHAPTER 7).
Precious Metals Indicator Code:AItem does not contain precious metal
Criticality Code:YThe item does not have a nuclear hardened feature but does have other critical feature(s) such as tolerance, fit restriction or application.
Automatic Data Processing Equipment:0Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9)
Category Code Description
NMF Description 061300 CIRCUIT BREAKER/SWITCH NOI
Less than car load rating P 77.5
Less than truck load rating P 77.5
Water commodity Code 658 unknown
Originating Activity Code HX Navy ICP
Mechanicsburg, PA 17055-0788
Air Dimension Code A Shipment is not a consolidation and does not exceed 72 inches in any dimension.
Air Commodity H Signal Corps supplies and equipment, including radio equipment and supplies, communications equipment and supplies, electrical equipment and supplies, etc.
Air Special Handling Z No special handling required.
Special Handling Code 9 unknonwn
HAZMAT
Type of Cargo Z No special type of cargo code applicable

Management | NSN 5945-00-480-8077

Category Code Description
Cognizance Codes1HConsumable material assigned to NAVICP MECH for inventory management
Naval Inventory Control Point, Mechanicsburg
Special Material IDX3Nuclear Reactor Plant (NRP) material under the technical cognizance of the NAVSEA 08 special designed, manufactured and/or treated for use in a NRP or controls thereof. This category includes all other NRP items which are not coded X2 or X4.
Issue Repair, or RequisitionBLSubmit/refer requisitions to NAVICP MECH. Centralized control for issue of repair parts for specific programs/equipments.
Source of SupplyNRPNAVICP-ERP
700 Robbins Avenue
Philadelphia, PA 19111-5098
AgencyDNDepartment of the Navy
Service OrganizationNU.S. Navy
ReparabilityMMedium Demand Velocity Items (consumables)
Acquisition Advice CodesVTERMINAL ITEM # Identifies items in stock, but future procurement is not authorized. Requisitions may continue to be submitted until stocks are exhausted. Preferred item National Stock Number is normally provided by application of the phrase: When Exhausted Use (NSN). Requisitions will be submitted in accordance with IMM/Service requisitioning procedures as applicable.
Controlled Item Code7NON-SENSITIVE (SRC-N/A) - UNCLASSIFIED AA&E: OR ITEMS ASSIGNED A DEMILITARIZATION CODE OTHER THAN A, B, Q, OR P FOR WHICH ANOTHER CIIC IS INAPPROPRIATE. (NOTE: THE LOSS, THEFT, UNLAWFUL DISPOSITION, AND/OR RECOVERY OF AN ITEM WITH CIIC 7 WILL BE INVESTIGATED IN ACCORDANCE WITH DOD-4000-25-2-M AND DOD 7200.14-R, VOLUME 12, CHAPTER 7).
Shelf Life Code0Nondeteriorative
Purchasing QTY
UOM
1
EA : Each
