Product Details | GROUNDING TERMINAL STRIP

5940-01-641-3269 A rigid metallic item of electrically conductive material. It is designed with terminal(s) and/or wire-accommodating holes on one end and facilities for connection to another conductive surface on the other end. For items without terminals or wire-accommodating facilities, see PLATE, ELECTRICAL GROUNDING; CONTACT STRIP, RADIO FREQUENCY GROUNDING; and STRIP, ELECTRICAL GROUNDING.

Part Alternates: 43033012273, 43033-01227-3 , 5940-01-641-3269, 01-641-3269, 5940016413269, 016413269

Electrical and Electronic Equipment Components | Lugs, Terminals, and Terminal Strips

Supply Group (FSG) NSN Assign. NIIN
59 2015016 01-641-3269

Request a Quote

What Our Customers Say

Compare

NSNs for Compare ( up to 4 ): Add 5940-01-641-3269

Technical Data | NSN 5940-01-641-3269

Characteristic Specifications
MATERIAL STEEL CORROSION RESISTING
SURFACE TREATMENT PASSIVATE
OVERALL LENGTH 2.48 INCHES NOMINAL
SPECIAL FEATURES 1/4-20-UNC-2A; NEXT ASSY: 43033-01443-1 AND 43033-00931-1; USED ON: AN/SPN-41B; DWG IS ITAR
PART NAME ASSIGNED BY CONTROLLING AGENCY (INAVY) GROUND STUD
III END ITEM IDENTIFICATION AN/SPN-41B

Restrictions/Controls & Freight Information | NSN 5940-01-641-3269

Category Code Description
Hazardous Material Indicator CodeNThere is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials
Demilitarization Code:ANon-Munitions List Item/ Non-Strategic List Item - Demilitarization not required.
Precious Metals Indicator Code:AItem does not contain precious metal
Criticality Code:X The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application.
Automatic Data Processing Equipment:0Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9)
Category Code Description
NMF Description 106120 PLATE/SHEET/STRIP I/S NOI
Less than car load rating
Less than truck load rating Q 70.0
Water commodity Code 72D unknown
Originating Activity Code HD Naval Inventory Control Point
Mechanicsburg, PA 17055-0788
Air Dimension Code A Shipment is not a consolidation and does not exceed 72 inches in any dimension.
Air Commodity H Signal Corps supplies and equipment, including radio equipment and supplies, communications equipment and supplies, electrical equipment and supplies, etc.
Air Special Handling Z No special handling required.
Special Handling Code 9 unknonwn
HAZMAT
Type of Cargo Z No special type of cargo code applicable

Management | NSN 5940-01-641-3269

Category Code Description
Cognizance Codes9BNavy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Source of SupplySMSDefense Logistics Agency
Enterprise Business Systems
AgencyDNDepartment of the Navy
Service OrganizationNU.S. Navy
Acquisition Advice CodesJNOT STOCKED, CENTRALLY PROCURED # (NON-STOCKED ITEMS) IMM/Service centrally managed but not stocked item. Procurement will be initiated only after receipt of a requisition.
Controlled Item CodeUUNCLASSIFIED
Shelf Life Code0Nondeteriorative
