Product Details | LUG TERMINAL
5940-00-754-7294 A terminal designed to be affixed, usually at one end, to a post, stud, chassis, or the like for mounting. It has provisions for attachment of wire(s) or similar electrical conductor(s) in order to establish an electrical connection and could require the use of tool(s) for attachment of wire. For post like terminals, see TERMINAL STUD. Excludes CLIP, ELECTRICAL; TERMINAL, QUICK DISCONNECT and TERMINAL FEEDTHRU.
Part Alternates: 321897, 5800X11, 5800X1-1, 5940-00-754-7294, 00-754-7294, 5940007547294, 007547294
Electrical and Electronic Equipment Components | Lugs, Terminals, and Terminal Strips
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 01 JAN 1962 | 00-754-7294 | 00746 ( TERMINAL, LUG ) |
Drawings & Photos | NSN 5940-00-754-7294
Demand History | NSN 5940-00-754-7294
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 321897 | 2019-04-107 | 36 | United States |
| 5940-00-754-7294 | 2018-10-287 | 1436 | DIBBS |
| 5940-00-754-7294 | 2013-02-54 | 2654 | DIBBS |
| 5940-00-754-7294 | 2013-02-39 | 2654 | DIBBS |
| 321897 | 2011-03-81 | 100 | US |
| 321897 | 2011-03-80 | 100 | IN |
| 321897 | 2011-03-77 | 100 | US |
| 5940-00-754-7294 | 2010-12-361 | 764 | DIBBS |
| 5940-00-754-7294 | 2010-04-99 | 231 | DIBBS |
| 5940-00-754-7294 | 2008-11-317 | 597 | DIBBS |
| 5940-00-754-7294 | 2008-10-301 | 660 | DIBBS |
| 5940-00-754-7294 | 2008-08-234 | 99 | DIBBS |
