NSN 5940-00-549-9251 GT805R83, GT805R8-3, TE55810
Product Details | LUG TERMINAL
5940-00-549-9251 A terminal designed to be affixed, usually at one end, to a post, stud, chassis, or the like for mounting. It has provisions for attachment of wire(s) or similar electrical conductor(s) in order to establish an electrical connection and could require the use of tool(s) for attachment of wire. For post like terminals, see TERMINAL STUD. Excludes CLIP, ELECTRICAL; TERMINAL, QUICK DISCONNECT and TERMINAL FEEDTHRU.
Part Alternates: GT805R83, GT805R8-3, TE55810, TE55-8-10, YAEV8CRS, YAV8CRS, 5M36808, 5M36-8-08, 10132151 , 10606781-7, 11616770, 545751, 54575-1, 5940-00-549-9251, 00-549-9251, 5940005499251, 005499251, 106067817
Electrical and Electronic Equipment Components | Lugs, Terminals, and Terminal Strips
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 01 JAN 1963 | 00-549-9251 | 00746 ( TERMINAL, LUG ) |
Drawings & Photos | NSN 5940-00-549-9251
Demand History | NSN 5940-00-549-9251
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| YAEV8CRS | 2012-04-107 | 100 | Netherlands |
| YAEV8CRS | 2010-04-99 | 30 | United States |
| 5940-00-549-9251 | 2008-07-199 | 250 | DIBBS |
Cross Reference | NSN 5940-00-549-9251
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 10606781-7 | 18876 | U S ARMY AVIATION AND MISSILE COMMAND |
| 11616770 | 19207 | U S ARMY TANK AUTOMOTIVE COMMAND AMSTA-IM-MM |
| 54575-1 | 00779 | TYCO ELECTRONICS CORPORATION |
| 5M36-8-08 | 76301 | BOEING COMPANY, THE DBA BOEING |
| GT805R8-3 | 26512 | NORTHROP GRUMMAN SYSTEMS CORPORATION DIV NORTHROP GRUMMAN AEROSPACE |
| TE55-8-10 | 14170 | HUGHES MISSILE SYSTEMS CO SAN DIEGO |
| YAEV8CRS | 09922 | SOURIAU USA, INC. |
| YAEV8CRS | 1NJK8 | BURNDY LLC |
| YAV8CRS | 22526 | FCI USA LLC |
