Product Details | ELECTRICAL PLUG CONNECTOR
5935-00-982-0396 An electrical fitting with electrical contacts, constructed to be affixed to the end of a cable, conduit, coaxial line, cord or wiring for convenience in joining with other electrical connector(s) or PRINTED WIRING BOARD and is not designed to be mounted on a bulkhead, chasses, panel, PRINTED WIRING BOARD, or the like. Excludes JACK, TELEPHONE; JACK, TIP; PLUG, TELEPHONE; PLUG TIP; INSERT, ELECTRICAL CONNECTOR; CONNECTOR BODY (as modified); and SOCKET, PLUG-IN, ELECTRONIC COMPONENTS. See also LEAD ASSEMBLY, ELECTRICAL; WIRING HARNESS (as modified); and CABLE ASSEMBLY (as modified). For items without inserts, see SHELL, ELECTRICAL CONNECTOR.
Part Alternates: 4268BC, 5935-00-982-0396, 00-982-0396, 5935009820396, 009820396
Electrical and Electronic Equipment Components | Connectors, Electrical
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 01 JAN 1962 | 00-982-0396 | 01938 ( CONNECTOR, PLUG, ELECTRICAL ) |
Drawings & Photos | NSN 5935-00-982-0396
Demand History | NSN 5935-00-982-0396
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 5935-00-982-0396 | 2018-04-119 | 1 | DIBBS |
| 5935-00-982-0396 | 2018-02-57 | 1 | DIBBS |
| 5935-00-982-0396 | 2018-02-57 | 2 | DIBBS |
| 5935-00-982-0396 | 2015-07-211 | 14 | DIBBS |
| 5935-00-982-0396 | 2011-08-238 | 1 | DIBBS |
| 5935-00-982-0396 | 2011-05-139 | 1 | DIBBS |
| 5935-00-982-0396 | 2011-03-63 | 1 | DIBBS |
| 5935-00-982-0396 | 2011-02-54 | 2 | DIBBS |
| 5935-00-982-0396 | 2010-10-303 | 1 | DIBBS |
| 5935-00-982-0396 | 2007-04-113 | 6 | DIBBS |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 5935-00-982-0396
Related Products | NSN 5935-00-982-0396
Technical Data | NSN 5935-00-982-0396
| Characteristic | Specifications |
|---|---|
| BODY STYLE | 11A STRAIGHT SHAPE, INTERNAL COUPLING W/STRAIN RELIEF |
| BODY LENGTH | 7.000 INCHES NOMINAL |
| OVERALL DIAMETER | 3.125 INCHES NOMINAL |
| CONNECTOR LOCKING METHOD | BAYONET PIN |
| THREADED DEVICE TYPE | BACK SHELL |
| THREAD SERIES DESIGNATOR | UNS |
| NOMINAL THREAD SIZE | 2.125 INCHES |
| THREAD CLASS | 2B |
| THREAD QUANTITY PER INCH | 16 |
| THREAD DIRECTION | RIGHT-HAND |
| NOMINAL THREAD LENGTH | 0.250 INCHES |
| CONNECTOR CABLE STRAIN RELIEF METHOD | CABLE CLAMP W/TELESCOPING BUSHING |
| CABLE ENTRANCE DIAMETER | 1.250 INCHES NOMINAL |
| SHELL TYPE | SOLID |
| SHELL MATERIAL | ALUMINUM ALLOY |
| POLARIZATION METHOD | 1 POLARIZATION POST |
| MATING END QUANTITY | 1 |
| CONTACT POSITION ARRANGEMENT STYLE | AECT 18-13 SINGLE MATING END |
| INSERT MATERIAL | PLASTIC POLYESTER SINGLE MATING END |
| INCLUDED CONTACT QUANTITY | 3 SINGLE MATING END 1ST CONTACT GROUPING 1 SINGLE MATING END 2ND CONTACT GROUPING |
| CONTACT REMOVABILITY | REMOVABLE SINGLE MATING END 1ST CONTACT GROUPING REMOVABLE SINGLE MATING END 2ND CONTACT GROUPING |
| CONTACT MAXIMUM CURRENT RATING IN AMPS | 60.0 SINGLE MATING END 1ST CONTACT GROUPING 60.0 SINGLE MATING END 2ND CONTACT GROUPING |
| CONTACT MAXIMUM AC VOLTAGE RATING IN VOLTS | 250.0 SINGLE MATING END 1ST CONTACT GROUPING 250.0 SINGLE MATING END 2ND CONTACT GROUPING |
| CONTACT MATERIAL | COPPER ALLOY SINGLE MATING END SINGLE CONTACT GROUPING |
| TERMINAL TYPE | SOLDER WELL SINGLE MATING END 1ST CONTACT GROUPING SCREW SINGLE MATING END 2ND CONTACT GROUPING |
| TERMINAL LOCATION | BACK SINGLE MATING END 1ST CONTACT GROUPING BACK SINGLE MATING END 2ND CONTACT GROUPING |
| ENVIRONMENTAL PROTECTION | EXPLOSION PROOF |
| MANUFACTURERS CODE | 78011 |
| DESIGN CONTROL REFERENCE | 4268BC |
