NSN 5930-01-344-6472 HP44473A, 44473A, 01-344-6472
Product Details | STEPPING SWITCH
5930-01-344-6472 An electromagnetically actuated switch having contact wipers which are successively rotated over fixed bank contacts. The contact wipers are progressively advanced over the fixed bank contacts through a repetitive series of stepping operations. The stepping operation may be a continuous forward rotation acting through 360 degrees to return to its normal unoperated position or it may be designed to include an electromagnetic and/or mechanical means for releasing and resetting the switch to its released position for a subsequent operation. The contact wipers may be mechanically held in contact with the fixed bank contacts after the armature of the actuating coil has released. The switch may be released at the end of its travel or at any intermediate position. It includes items designed with two electromagnetic actuators that enable the switch to operate in either direction. For items having the dual function of a switch and a relay assembled together on a common mounting, see RELAY-SWITCH. For other than electromagnetically actuated switches whose contact wipers are manually rotated over fixed bank contacts, see SWITCH, ROTARY. Excludes RELAY, ROTARY and SWITCH, TELEPHONE (as modified).
Part Alternates: HP44473A, 44473A, 5930-01-344-6472, 01-344-6472, 5930013446472, 013446472
Electrical and Electronic Equipment Components | Switches
Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
---|---|---|---|
59 | 05 SEP 1991 | 01-344-6472 | 26954 ( SWITCH, STEPPING ) |
Request a Quote
What Our Customers Say
Compare
Related Products | NSN 5930-01-344-6472
Technical Data | NSN 5930-01-344-6472
Characteristic | Specifications |
---|---|
III END ITEM IDENTIFICATION | AN.USC-28 |
Restrictions/Controls & Freight Information | NSN 5930-01-344-6472
Category | Code | Description |
---|---|---|
Shelf-Life Code: | 0 | Nondeteriorative |
Hazardous Material Indicator Code | P | There is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product |
Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
Controlled Inventory Item Code: | U | UNCLASSIFIED |
Electro-static Discharge Susceptible: | A | No known Electrostatic Discharge (ESD) or Electromagnetic Interference (EMI) sensitivity |
Precious Metals Indicator Code: | A | Item does not contain precious metal |
Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
Category | Code | Description |
---|---|---|
NMF Description | 061300 | CIRCUIT BREAKER/SWITCH NOI |
Less than car load rating | P | 77.5 |
Less than truck load rating | P | 77.5 |
Water commodity Code | 658 | unknown |
Originating Activity Code | CL | U.S. Army Communications-Electronics Fort Monmouth, NJ 07703-5006 |
Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
Air Commodity | H | Signal Corps supplies and equipment, including radio equipment and supplies, communications equipment and supplies, electrical equipment and supplies, etc. |
Air Special Handling | Z | No special handling required. |
Special Handling Code | 9 | unknonwn |
HAZMAT | ||
Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 5930-01-344-6472
Category | Code | Description |
---|---|---|
Materiel Category and Inventory Manager | G | Communications and Electronics Equipment, Electronics Materiel |
Appropriation and Budget Activity | 2 | Stock Fund Secondary Items |
Management Inventory Segment | 4 | PROVISIONING ITEMS (Exclusive of Insurance Items). This code will identify new items introduced through the provisioning process for system stock which would normally be categorized as either nonreparable or reparable but for which sufficient experience has been obtained to manage on the basis of normal demand forecasts. |
Specific Group/Generic Code | 4 | Communications Systems Agency and Satellite Communications |
Weapons Systems/End Item or Homogeneous Group | 4U | AN/USC-28 |
Accounting Requirements Code | X | Expendable item. An item of Army property coded with an ARC of ?X? in the AMDF. Expendable items require no formal accountability after issue from a stock record account. Commercial and fabricated items similar to items coded ?X? in the AMDF are considered expendable items. |
Source of Supply | B16 | US Army Communications-Electronics Command and Fort Monmouth Fort Monmouth, NJ 07703-5016 |
Agency | DA | Department of the Army |
Service Organization | L | Lead Service - 22 (Repairable) |
Reparability | D | When repair is beyond lower level maintenance capability, evacuate the item to depot. Disposal is not authorized below wholesale level. |
Acquisition Advice Codes | F | FABRICATE OR ASSEMBLE # (NON-STOCKED ITEMS) National Stock Numbered items fabricated or assembled from raw materials and finished products as the normal method of support. Procurement and stockage of the items are not justified because of low usage or peculiar installation factors. Distinctions between local or centralized fabricate/assemble capability are identified by the Source of Supply Modifier in the Source of Supply Column of the Service Management Data Lists. |
Controlled Item Code | U | UNCLASSIFIED |
Shelf Life Code | 0 | Nondeteriorative |
