NSN 5930-01-080-5455 07A0194, 07-A-0194, 3893221
Product Details | SWITCH ASSEMBLY
5930-01-080-5455 Two or more complete switches mounted on each other or having a common mounting the major function of which is to hold the switches. Each switch, as a separable item, must be capable of functioning in accordance with its own name. Excludes items consisting of individually separable switches which are physically interlocked (e.g., one button returns when the other is pushed), which have a common actuator, or are electrically connected. See also SWITCH, PUSH.
Part Alternates: 07A0194, 07-A-0194, 3893221, 389322-1, 7A194, 7-A-194, 5930-01-080-5455, 01-080-5455, 5930010805455, 010805455
Electrical and Electronic Equipment Components | Switches
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 27 JUL 1979 | 01-080-5455 | 00711 ( SWITCH ASSEMBLY ) |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 5930-01-080-5455
Technical Data | NSN 5930-01-080-5455
| Characteristic | Specifications |
|---|---|
| INDIVIDUAL SWITCH QUANTITY | 4 |
| SWITCH TYPE | ROTARY |
| CONTROLLING AGENCY | DIGITRON CO |
| IDENTIFYING NUMBER | 700 TYPE NO. |
| INCLOSURE TYPE | FULLY INCLOSED |
| INCLOSURE MATERIAL | PLASTIC, ARC RESISTANT |
| ENVIRONMENTAL PROTECTION | MOISTURE RESISTANT AND SHOCK PROOF AND VIBRATION PROOF |
| OVERALL LENGTH | 2.777 INCHES NOMINAL |
| OVERALL WIDTH | 1.150 INCHES NOMINAL |
| OVERALL HEIGHT | 2.135 INCHES NOMINAL |
| MOUNTING METHOD | HOLE |
| MOUNTING CONFIGURATION | FOUR 0.100 IN. DIA MTG HOLES SPACED ON 2.600 IN. BY 0.900 IN. MTG CENTERS |
| SPECIAL FEATURES | ILLUMINATED DIGITS; 3 AMPS AT 115 VAC; BREAK AT 0.100 AMPS 115 VAC OR 28 VDC |
| III PRECIOUS MATERIAL | GOLD |
| III PRECIOUS MATERIAL AND LOCATION | STATOR CONTACT SURFACES GOLD |
Restrictions/Controls & Freight Information | NSN 5930-01-080-5455
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | P | There is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | G | Item contains gold |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 061300 | CIRCUIT BREAKER/SWITCH NOI |
| Less than car load rating | ||
| Less than truck load rating | P | 77.5 |
| Water commodity Code | 72D | unknown |
| Originating Activity Code | TX | Defense Supply Center Columbus Columbus, OH 43218 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | H | Signal Corps supplies and equipment, including radio equipment and supplies, communications equipment and supplies, electrical equipment and supplies, etc. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 5930-01-080-5455
Air Force| Category | Code | Description |
|---|---|---|
| Budget Code | 9 | General Support DIV57X4921.070:Air Force decentrally managed expense items (ERRC XB3, XF-3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors. |
| Price Validation | N | The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
|
| Fund Code | SF | Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point. |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DF | Department of the Air Force |
| Service Organization | F | U.S. Air Force |
| Reparability | N | Stock Fund (except Munitions) |
| Acquisition Advice Codes | J | NOT STOCKED, CENTRALLY PROCURED # (NON-STOCKED ITEMS) IMM/Service centrally managed but not stocked item. Procurement will be initiated only after receipt of a requisition. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
