NSN 5930-01-047-8919 2SEA51104C28M, 2SEA51-104C28M, 01-047-8919
Product Details | FLOW SWITCH
5930-01-047-8919 A switch which is specifically designed to operate by the influence of a gaseous, liquid, or solid media velocity on its actuator.
Part Alternates: 2SEA51104C28M, 2SEA51-104C28M, 5930-01-047-8919, 01-047-8919, 5930010478919, 010478919
Electrical and Electronic Equipment Components | Switches
Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
---|---|---|---|
59 | 15 SEP 1977 | 01-047-8919 | 36841 ( SWITCH, FLOW ) |
Request a Quote
What Our Customers Say
Compare
NSNs for Compare ( up to 4 ): Add 5930-01-047-8919
Related Products | NSN 5930-01-047-8919
Technical Data | NSN 5930-01-047-8919
Characteristic | Specifications |
---|---|
OVERALL LENGTH | 3.284 INCHES MINIMUM AND 3.346 INCHES MAXIMUM |
BODY DIAMETER | 0.500 INCHES NOMINAL |
NONPILE-UP CONTACT ARRANGEMENT | 1 POLE, SINGLE THROW, NORMALLY CLOSED, MOMENTARY ACTION |
CONTACT ACTION STIMULUS | INCREASE |
CONTACT ADJUSTABILITY | DEACTUATION POINT NOT ADJUSTABLE AND ACTUATION POINT NOT ADJUSTABLE |
CONTACT STIMULUS RATING | 100.00 ACTUATION POINT MINIMUM FEET PER MINUTE AND 500.00 ACTUATION POINT MAXIMUM FEET PER MINUTE |
CONTACT VOLTAGE RATING IN VOLTS | 28.0 DC AT SEA LEVEL SINGLE VOLTAGE |
CONTACT LOAD CURRENT RATING | 400.0 MILLIAMPERES RESISTIVE LOAD SINGLE VOLTAGE |
OPERATING TEMP RATING | 50.0 DEG FAHRENHEIT MINIMUM AND 120.0 DEG FAHRENHEIT MAXIMUM |
MEDIA FOR WHICH DESIGNED | GAS |
TERMINAL TYPE | QUICK DISCONNECT, MALE |
MOUNTING METHOD | BRACKET AND UNTHREADED HOLE |
SPECIAL FEATURES | DESIGNED FOR MILITARY APPLICATIONS |
III PRECIOUS MATERIAL | GOLD |
III PRECIOUS MATERIAL AND LOCATION | TERMINAL SURFACES GOLD |
Restrictions/Controls & Freight Information | NSN 5930-01-047-8919
Category | Code | Description |
---|---|---|
Shelf-Life Code: | 0 | Nondeteriorative |
Hazardous Material Indicator Code | P | There is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product |
Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
Controlled Inventory Item Code: | U | UNCLASSIFIED |
Precious Metals Indicator Code: | G | Item contains gold |
Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
Category | Code | Description |
---|---|---|
NMF Description | 061300 | CIRCUIT BREAKER/SWITCH NOI |
Less than car load rating | ||
Less than truck load rating | P | 77.5 |
Water commodity Code | 658 | unknown |
Originating Activity Code | TX | Defense Supply Center Columbus Columbus, OH 43218 |
Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
Air Commodity | H | Signal Corps supplies and equipment, including radio equipment and supplies, communications equipment and supplies, electrical equipment and supplies, etc. |
Air Special Handling | Z | No special handling required. |
Special Handling Code | 9 | unknonwn |
HAZMAT | ||
Type of Cargo | Z | No special type of cargo code applicable |
