NSN 5930-00-952-9031 MS167121, MS16712-1, MS167211

Product Details | PUSH SWITCH

5930-00-952-9031 A switch that is externally actuated by a device such as a push rod or button, which requires pushing for each actuation. The action may be momentary, with mechanical return. The actuating device may or may not be an integral part of the switch. The item may include provisions for mounting indicating lamp(s) or light emitting diode(s) in the actuator. Includes items consisting of individually separable switches that are physically interlocked, that have a common actuator, or are electrically connected. Excludes LIGHT-SWITCH; LIGHT-SWITCH ASSEMBLY; SWITCH, BEAM SELECTING, HEADLIGHT; SWITCH, FOOT; SWITCH, INTERLOCK; SWITCH, PRESSURE; SWITCH, PUSH-PULL; SWITCH, SENSITIVE and SWITCH ASSEMBLY. For devices which start, stop, reverse, select and/or regulate the speed of a motor, see STARTER, MOTOR and CONTROLLER, MOTOR.

Part Alternates: MS167121, MS16712-1, MS167211, MS16721-1, C20050MS167121, C20050-MS16712-1, MIL-PRF-8805/20, MILPRF880520, MIL-S-8805/20, MILS880520, 044X206, 31802001, 318-02-001, 5749064-020REV D, 5749064020REVD, 5930-00-952-9031, 00-952-9031, 5930009529031, 009529031

Electrical and Electronic Equipment Components | Switches

Supply Group (FSG)	NSN Assign.	NIIN	Item Name Code (INC)
59	01 JAN 1960	00-952-9031	00406 ( SWITCH, PUSH )

Drawings & Photos | NSN 5930-00-952-9031

Part Number	Request Date	QTY	Origin
5930-00-952-9031	2025-03-77	1	US
5930-00-952-9031	2023-11-317	500	DIBBS
5930-00-952-9031	2023-07-212	923	DIBBS
5930-00-952-9031	2023-07-201	923	DIBBS
5930-00-952-9031	2023-05-135	575	DIBBS
5930-00-952-9031	2023-03-65	411	DIBBS
5930-00-952-9031	2022-10-276	342	DIBBS
5930-00-952-9031	2022-09-265	342	DIBBS
5930-00-952-9031	2022-07-202	297	DIBBS
5930-00-952-9031	2022-06-175	587	DIBBS
5930-00-952-9031	2022-06-164	587	DIBBS
5930-00-952-9031	2022-03-66	143	DIBBS
5930-00-952-9031	2022-01-06	201	DIBBS
5930-00-952-9031	2021-11-312	123	DIBBS
5930-00-952-9031	2021-09-256	36	DIBBS
5930-00-952-9031	2021-08-222	178	DIBBS
5930-00-952-9031	2021-07-189	62	DIBBS
5930-00-952-9031	2021-05-134	1	Taiwan
5930-00-952-9031	2021-04-95	66	DIBBS
5930-00-952-9031	2021-01-05	64	DIBBS
5930-00-952-9031	2020-04-114	47	DIBBS
5930-00-952-9031	2020-02-41	172	DIBBS
5930-00-952-9031	2020-01-30	172	DIBBS
5930-00-952-9031	2020-01-05	137	DIBBS
5930-00-952-9031	2019-12-338	32	DIBBS
5930-00-952-9031	2019-10-276	2	ID
5930-00-952-9031	2019-08-230	300	DIBBS
5930-00-952-9031	2019-08-223	150	DIBBS
5930-00-952-9031	2019-04-111	44	DIBBS
5930-00-952-9031	2018-08-236	1	AU
5930-00-952-9031	2018-05-121	2	US
5930-00-952-9031	2018-04-115	4	US
5930-00-952-9031	2017-11-320	1	MANUAL
MS16712-1	2017-11-320	1	United States
5930-00-952-9031	2017-10-295	2	UK
MS167121	2015-11-313	4	IN
5930-00-952-9031	2015-07-210	836	DIBBS
5930-00-952-9031	2015-06-174	245	DIBBS
5930-00-952-9031	2015-05-139	442	DIBBS
5930-00-952-9031	2015-02-36	333	DIBBS
5930-00-952-9031	2014-03-77	336	DIBBS
5930-00-952-9031	2013-11-316	319	DIBBS
5930-00-952-9031	2013-03-78	336	DIBBS
5930-00-952-9031	2011-12-336	5	China
5930-00-952-9031	2011-11-333	181	DIBBS
5930-00-952-9031	2011-10-286	400	DIBBS
5930-00-952-9031	2011-09-264	5	MANUAL
MS16712-1	2011-09-264	5	Hong Kong
5930-00-952-9031	2011-08-215	590	DIBBS
5930-00-952-9031	2011-07-187	3	US
5930-00-952-9031	2011-07-187	6	US
5930-00-952-9031	2011-06-164	3	US
5930-00-952-9031	2011-06-164	150	DIBBS
C20050MS167121	2011-04-109	70	US
5930-00-952-9031	2011-02-33	4	US
MS167121	2010-09-267	2	United States
5930-00-952-9031	2010-06-169	50	Brazil
MILS880520	2010-05-131	7	US
5930-00-952-9031	2009-09-272	106	DIBBS
MS167121	2009-08-240	1	United States
5930-00-952-9031	2008-08-226	504	DIBBS
5930-00-952-9031	2008-01-30	250	DIBBS
5930-00-952-9031	2007-12-344	300	DIBBS

Cross Reference | NSN 5930-00-952-9031

Part Number	Cage Code	Manufacturer
044X206	07618	DUCOMMUN LABARGE TECHNOLOGIES, INC. DBA LABARGE INC ELECTRONICS DIV
318-02-001	58475	WESTWOOD CORPORATION DBA NMP DIVISION
5749064-020REV D	53711	NAVAL SEA SYSTEMS COMMAND
C20050-MS16712-1	81640	EATON CORPORATION DBA FLUID POWER DIV
MIL-PRF-8805/20	81349	MILITARY SPECIFICATIONS PROMULGATED BY MILITARY
MIL-S-8805/20	81349	MILITARY SPECIFICATIONS PROMULGATED BY MILITARY
MS16712-1	81349	MILITARY SPECIFICATIONS PROMULGATED BY MILITARY
MS16712-1	96906	MILITARY STANDARDS PROMULGATED BY MILITARY DEPARTMENTS
MS16712-1	96909	DE MARZI VICTOR
MS16721-1	96906	MILITARY STANDARDS PROMULGATED BY MILITARY DEPARTMENTS

Request a Quote

What Our Customers Say

Thank you very much for the excellent service and professional customer care.

Ernie G. Honeywell

The service was excellent. I can think of no improvements to date that you can make regarding internet sales.

John L. Raytheon

The representative for WBParts was efficient & handled our request in a timely & professional manner.

Karen G. General Dynamics

Tried two other sources, neither of them responded, was all done online, never spoke to anyone.

Rex S. US Airforce

The response is quick and the price is often very good. We are completely satisfied.

Patricia S. NASA

Compare

NSNs for Compare ( up to 4 ): Add 5930-00-952-9031

Compare

Related Products | NSN 5930-00-952-9031

5930-00-952-9489, 5930-00-952-9531, 5930-00-952-9536, 5930-00-953-0162, 5930-00-953-0384

Technical Data | NSN 5930-00-952-9031

Characteristic	Specifications
NONPILE-UP CONTACT ARRANGEMENT	1 TWO CIRCUIT, DOUBLE BREAK/DOUBLE MAKE, ONE POSITION MOMENTARY SINGLE SWITCH UNIT
MAXIMUM VOLTAGE RATING IN VOLTS	120.0 AC AND 120.0 DC
CONTACT LOAD CURRENT RATING AT MAXIMUM RATED VOLTAGE	1.000 AMPERES RESISTIVE DC AND 15.000 AMPERES RESISTIVE AC
BODY STYLE	5K BUSHING MOUNTED
BODY DIAMETER	0.547 INCHES MINIMUM AND 0.577 INCHES MAXIMUM
BUSHING LENGTH	0.235 INCHES MINIMUM AND 0.265 INCHES MAXIMUM
BODY LENGTH	0.408 INCHES MINIMUM AND 0.438 INCHES MAXIMUM
ACTUATOR STYLE	8 ROUND
ACTUATOR DIAMETER	0.297 INCHES MINIMUM AND 0.327 INCHES MAXIMUM
ACTUATOR HEIGHT	0.172 INCHES MINIMUM AND 0.202 INCHES MAXIMUM
ACTUATOR COLOR	BLACK SINGLE ACTUATOR
TERMINAL TYPE AND QUANTITY	4 SCREW
INCLOSURE TYPE	FULLY INCLOSED
MOUNTING METHOD	THREADED BUSHING
THREAD SERIES DESIGNATOR	UN
NOMINAL THREAD SIZE	0.500 INCHES
THREAD CLASS	2A
THREAD QUANTITY PER INCH	32
TEST DATA DOCUMENT	81349-MIL-S-8805 SPECIFICATION
SPECIFICATION/STANDARD DATA	96906-MS16712 GOVERNMENT STANDARD
III OVERALL LENGTH	1.250 INCHES NOMINAL
III OVERALL WIDTH	0.562 INCHES NOMINAL
III OVERALL HEIGHT	0.562 INCHES NOMINAL
MANUFACTURERS CODE	81349
NON-DEFINITIVE GOVERNMENT SPEC/STD REFERENCE	MIL-S-8805/20
MANUFACTURERS CODE	96906
DEFINITIVE GOVERNMENT SPEC/STD REFERENCE	MS16712-1

Restrictions/Controls & Freight Information | NSN 5930-00-952-9031

Restrictions
Freight

Category	Code	Description
Shelf-Life Code:	0	Nondeteriorative
Hazardous Material Indicator Code	P	There is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product
Demilitarization Code:	A	Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required.
Controlled Inventory Item Code:	U	UNCLASSIFIED
Precious Metals Indicator Code:	U	Precious metal type is unknown
Criticality Code:	X	The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application.

Category	Code	Description
NMF Description	061300	CIRCUIT BREAKER/SWITCH NOI
Less than car load rating
Less than truck load rating	P	77.5
Water commodity Code	72D	unknown
Originating Activity Code	XX
Air Dimension Code	A	Shipment is not a consolidation and does not exceed 72 inches in any dimension.
Air Commodity	H	Signal Corps supplies and equipment, including radio equipment and supplies, communications equipment and supplies, electrical equipment and supplies, etc.
Air Special Handling	Z	No special handling required.
Special Handling Code	9	unknonwn
HAZMAT
Type of Cargo	Z	No special type of cargo code applicable

Management | NSN 5930-00-952-9031

Category	Code	Description
Materiel Category and Inventory Manager	Q	Electronics Materiel (DLA/GSA Items)
Appropriation and Budget Activity	2	Stock Fund Secondary Items
Management Inventory Segment	2	NONREPARABLE ITEMS (Exclusive of Insurance and Provisioning Items). This code will be used to identify items which are not reparable.
Specific Group/Generic Code	0	Medical Materiel
Weapons Systems/End Item or Homogeneous Group	00	DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
Accounting Requirements Code	X	Expendable item. An item of Army property coded with an ARC of ?X? in the AMDF. Expendable items require no formal accountability after issue from a stock record account. Commercial and fabricated items similar to items coded ?X? in the AMDF are considered expendable items.
Source of Supply	SMS	Defense Logistics Agency Enterprise Business Systems
Agency	DA	Department of the Army
Service Organization	A	U.S. Army
Reparability	Z	This is a nonreparable item. If condemned or economically unserviceable, then dispose at the level authorized replace the item.
Acquisition Advice Codes	D	DoD INTEGRATED MATERIEL-MANAGED, STOCKED, AND ISSUED # Issue, transfer, or shipment is not subject to specialized controls other than those imposed by the Integrated Materiel Manager/Service supply policy. 1. The item is centrally managed, stocked, and issued. 2. Requisitions must contain the fund citation required to acquire the item. Requisitions will be submitted in accordance with Integrated Materiel Manager(IMM)/Service requisitioning procedures.
Controlled Item Code	U	UNCLASSIFIED
Shelf Life Code	0	Nondeteriorative
Purchasing	QTY UOM	1 EA : Each

Category	Code	Description
Budget Code	9	General Support DIV57X4921.070:Air Force decentrally managed expense items (ERRC XB3, XF-3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors.
Materiel Management Aggregation Code	EH	SX:ELECTRONIC COMPONENTS
Fund Code	SF	Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point.
Price Validation	V	The current standard price has been validated. The item has been analyzed in conjunction with the Zero Overpricing Program and is in the accepted price range. The item was procured under open competition and under the competitive arena the price is considered fair and reasonable. ZOP or Standard price challenges are permissible but must be supported by adequate justification.
Source of Supply	SMS	Defense Logistics Agency Enterprise Business Systems
Agency	DF	Department of the Air Force
Service Organization	F	U.S. Air Force
Reparability	N	Stock Fund (except Munitions)
Acquisition Advice Codes	D	DoD INTEGRATED MATERIEL-MANAGED, STOCKED, AND ISSUED # Issue, transfer, or shipment is not subject to specialized controls other than those imposed by the Integrated Materiel Manager/Service supply policy. 1. The item is centrally managed, stocked, and issued. 2. Requisitions must contain the fund citation required to acquire the item. Requisitions will be submitted in accordance with Integrated Materiel Manager(IMM)/Service requisitioning procedures.
Controlled Item Code	U	UNCLASSIFIED
Shelf Life Code	0	Nondeteriorative
Purchasing	QTY UOM	1 EA : Each

Category	Code	Description
Stores Account Code	1	Marine Corps Stock Fund Account Item.
Combat Essentiality Code	5	Critical Repair Part to a Combat Essential End Item. Those parts or components whose failure in a combat essential end item will render the end item inoperative or reduce its effectiveness below the minimum acceptable level of efficiency.
Materiel Management Code	B	All CommoditiesDefense Logistics Agency, (DLA,)
Echelon Management Code	2	ICP/DSSC Marine Corps-managed Recoverability Code D items and Defense Logistics Agency (DLA)/TACOM/GSA) items which the integrated manager has not decontrolled.
Echelon Identification Code	B	Consumable Repair Parts
Source of Supply	SMS	Defense Logistics Agency Enterprise Business Systems
Agency	DM	U.S. Marine Corps
Service Organization	M	U.S. Marine Corps
Reparability	Z	Nonreparable item. When unserviceable, condemn and dispose at the level indicated by the first digit of the maintenance code.
Acquisition Advice Codes	D	DoD INTEGRATED MATERIEL-MANAGED, STOCKED, AND ISSUED # Issue, transfer, or shipment is not subject to specialized controls other than those imposed by the Integrated Materiel Manager/Service supply policy. 1. The item is centrally managed, stocked, and issued. 2. Requisitions must contain the fund citation required to acquire the item. Requisitions will be submitted in accordance with Integrated Materiel Manager(IMM)/Service requisitioning procedures.
Controlled Item Code	U	UNCLASSIFIED
Shelf Life Code	0	Nondeteriorative
Purchasing	QTY UOM	1 EA : Each

Category	Code	Description
Cognizance Codes	9B	Navy-owned stocks of DLA material Naval Inventory Control Point, Mechanicsburg
Special Material Content	9	Non-Hazardous or Non-Sensitive Item, does not require hazardous or special handling, packaging or precautions
Source of Supply	SMS	Defense Logistics Agency Enterprise Business Systems
Agency	DN	Department of the Navy
Service Organization	N	U.S. Navy
Acquisition Advice Codes	D	DoD INTEGRATED MATERIEL-MANAGED, STOCKED, AND ISSUED # Issue, transfer, or shipment is not subject to specialized controls other than those imposed by the Integrated Materiel Manager/Service supply policy. 1. The item is centrally managed, stocked, and issued. 2. Requisitions must contain the fund citation required to acquire the item. Requisitions will be submitted in accordance with Integrated Materiel Manager(IMM)/Service requisitioning procedures.
Controlled Item Code	U	UNCLASSIFIED
Shelf Life Code	0	Nondeteriorative
Purchasing	QTY UOM	1 EA : Each
