Product Details | SWITCH SUBASSEMBLY
5930-00-862-3515 Two or more different types of items having a common mounting or mounted on each other which together forms a portion of a switch but which in itself is not a complete functioning item and cannot be assigned a more definite item name. See also SWITCH SECTION, ROTARY and CONTACT ASSEMBLY, ELECTRICAL.
Part Alternates: M208957, PC737074, PC73707-4, 23853586, 2385358-6, 2D8, 89834351, 8983435-1, 5930-00-862-3515, 00-862-3515, 5930008623515, 008623515
Electrical and Electronic Equipment Components | Switches
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 01 JAN 1962 | 00-862-3515 | 00621 ( SWITCH SUBASSEMBLY ) |
Drawings & Photos | NSN 5930-00-862-3515
Demand History | NSN 5930-00-862-3515
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 5930-00-862-3515 | 2019-07-205 | 4 | United States |
Cross Reference | NSN 5930-00-862-3515
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 2385358-6 | 56232 | LOCKHEED MARTIN CORPORATION DBA LOCKHEED MARTIN |
| 2D8 | 91929 | HONEYWELL INTERNATIONAL INC. DBA HONEYWELL |
| 8983435-1 | 02734 | LOCKHEED MARTIN CORPORATION DBA LOCKHEED MARTIN |
| 8983435-1 | 49671 | LOCKHEED MARTIN CORP LOCKHEED MARTIN INFORMATION SYSTEMS |
| M208957 | F1219 | CIE IBM FRANCE |
| PC73707-4 | U0380 | BAE SYSTEMS ADVANCED TECHNOLOGY CENT |
