NSN 5930-00-603-7698 PA1, PA-1, 00-603-7698
Product Details | ROTARY SWITCH SECTION
5930-00-603-7698 An item consisting of electrical contacts mounted on an insulated plate which together form a section of a switch or relay. It includes both rotor and stator but does not include drive or actuating mechanism.
Part Alternates: PA1, PA-1, 5930-00-603-7698, 00-603-7698, 5930006037698, 006037698
Electrical and Electronic Equipment Components | Switches
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 01 JAN 1963 | 00-603-7698 | 15315 ( SWITCH SECTION, ROTARY ) |
Drawings & Photos | NSN 5930-00-603-7698
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 5930-00-603-7698
Related Products | NSN 5930-00-603-7698
Technical Data | NSN 5930-00-603-7698
| Characteristic | Specifications |
|---|---|
| SWITCH CONTACT BASIC DESIGN | NONPILE-UP SYMMETRICAL |
| POLE QUANTITY | 1 SINGLE SECTION FRONT |
| THROW QUANTITY | 2 SINGLE SECTION FRONT |
| CONTACT SWITCHING ACTION | BREAKS BEFORE MAKES SINGLE SECTION FRONT |
| TERMINAL TYPE | TAB, SOLDER LUG |
| MOUNTING METHOD | STRUT SINGLE MOUNTING FACILITY |
| MANUFACTURERS CODE | 79692 |
| DESIGN CONTROL REFERENCE | PA-1 |
Restrictions/Controls & Freight Information | NSN 5930-00-603-7698
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | P | There is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | U | Precious metal type is unknown |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 061300 | CIRCUIT BREAKER/SWITCH NOI |
| Less than car load rating | ||
| Less than truck load rating | P | 77.5 |
| Water commodity Code | 658 | unknown |
| Originating Activity Code | XX | |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | H | Signal Corps supplies and equipment, including radio equipment and supplies, communications equipment and supplies, electrical equipment and supplies, etc. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
