NSN 5910-01-435-7736 CS311110, 9082750010, 908-275-0010
Product Details | CAPACITOR ASSEMBLY
5910-01-435-7736 Two or more separable CAPACITOR, FIXED (as modified) and/or CAPACITOR, VARIABLE (as modified) having a common mounting or mounted on each other. Excludes single fixed capacitors with multiple sections; single variable capacitors with integral trimmers or with multiple sections actuated by a single shaft; CAPACITOR ASSORTMENT; and CAPACITOR SET, MATCHED.
Part Alternates: CS311110, 9082750010, 908-275-0010, B401, 5910-01-435-7736, 01-435-7736, 5910014357736, 014357736
Electrical and Electronic Equipment Components | Capacitors
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 31 AUG 1996 | 01-435-7736 | 00453 ( CAPACITOR ASSEMBLY ) |
Demand History | NSN 5910-01-435-7736
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| B401 | 2023-07-187 | 4 | US |
| B401 | 2021-06-166 | 2 | US |
| 5910-01-435-7736 | 2007-06-159 | 2 | DIBBS |
| 5910-01-435-7736 | 2007-04-110 | 1 | DIBBS |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 5910-01-435-7736
Related Products | NSN 5910-01-435-7736
Technical Data | NSN 5910-01-435-7736
| Characteristic | Specifications |
|---|---|
| COMPONENT RELATIONSHIP | MATCHED TO EACH OTHER |
| COMPONENT NAME | FIXED ELECTROLYTIC CAPACITOR |
| COMPONENT CONTROLLING AGENCY | NORDEN SYSTEMS |
| CAPACITANCE VALUE | 7000.0 MICROFARADS |
| CAPACITANCE TOLERANCE IN PERCENT | -10.0 TO 10.0 |
| TERMINAL QUANTITY | 2 |
| TERMINAL TYPE | WIRE LEAD |
| MOUNTING METHOD | THREAD INSERT |
| MOUNTING CONFIGURATION | FOUR NO. 4-40 THREADED INSERTS SPACED 1.300 IN. BY 2.300 IN. C TO C |
| OVERALL LENGTH | 2.624 INCHES MAXIMUM |
| OVERALL HEIGHT | 1.000 INCHES MAXIMUM |
| OVERALL WIDTH | 1.600 INCHES MAXIMUM |
Restrictions/Controls & Freight Information | NSN 5910-01-435-7736
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | P | There is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 061400 | CONDENSERS/PARTS NOI/CAPACITORS |
| Less than car load rating | ||
| Less than truck load rating | P | 77.5 |
| Water commodity Code | 72D | unknown |
| Originating Activity Code | TH | Defense Supply Center Columbus Columbus, OH 43215 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | H | Signal Corps supplies and equipment, including radio equipment and supplies, communications equipment and supplies, electrical equipment and supplies, etc. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 5910-01-435-7736
Air Force| Category | Code | Description |
|---|---|---|
| Budget Code | 9 | General Support DIV57X4921.070:Air Force decentrally managed expense items (ERRC XB3, XF-3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors. |
| Materiel Management Aggregation Code | EH | SX:ELECTRONIC COMPONENTS |
| Price Validation | N | The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
|
| Fund Code | SF | Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point. |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DF | Department of the Air Force |
| Service Organization | F | U.S. Air Force |
| Reparability | N | Stock Fund (except Munitions) |
| Acquisition Advice Codes | Z | INSURANCE/NUMERIC STOCKAGE OBJECTIVE ITEM # Items which may be required occasionally or intermittently, and prudence requires that a nominal quantity of materiel be stocked due to the essentiality or the lead time of the item. 1. The item is centrally managed, stocked, and issued. 2. Requisitions will be submitted in accordance with IMM/Service requisitioning procedures. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
