Product Details | PAPER DIELECTRIC FIXED CAPACITOR

5910-00-553-6495 A capacitor whose capacitance value cannot be adjusted or varied, having paper as the dielectric material. It may be a single unit or consist of two or more fixed units which cannot be seperated. For items whose dielectric material consist of plasticized (plastic impregnated) paper or paper-plastic combinations, see CAPACITOR, FIXED, PLASTIC DIELECTRIC. For items whose electrodes consist of a metallic film deposited (metallized) on the dielectric material, see CAPACITOR, FIXED, METALIZED, PAPER-PLASTIC DIELECTRIC.

Part Alternates: N208824348, N2088243-48, GPS514543, GPS51454-3, 2088243-48, 191P22451S4, 5910-00-553-6495, 00-553-6495, 5910005536495, 005536495, 208824348

Electrical and Electronic Equipment Components | Capacitors

Supply Group (FSG) NSN Assign. NIIN
59 01 JAN 1963 00-553-6495

Drawings & Photos | NSN 5910-00-553-6495


Cross Reference | NSN 5910-00-553-6495

Part Number Cage Code Manufacturer
191P22451S4 56289 SPRAGUE ELECTRIC CO WORLD HQS
2088243-48 94931 BENDIX CORP THE BENDIX INTERNATIONAL DIV
GPS51454-3 96214 RAYTHEON COMPANY DBA RAYTHEON
N2088243-48 94931 BENDIX CORP THE BENDIX INTERNATIONAL DIV

Request a Quote

What Our Customers Say

Compare

NSNs for Compare ( up to 4 ): Add 5910-00-553-6495

Technical Data | NSN 5910-00-553-6495

Characteristic Specifications
CAPACITANCE VALUE PER SECTION 0.220 MICROFARADS SINGLE SECTION
TOLERANCE RANGE PER SECTION -5.00 TO 5.00 PERCENT SINGLE SECTION
NONDERATED CONTINUOUS VOLTAGE RATING AND TYPE PER SECTION 100.0 DC SINGLE SECTION
NONDERATED OPERATING TEMP -55.0 DEG CELSIUS MINIMUM AND 85.0 DEG CELSIUS MAXIMUM
BODY STYLE 26B W/O MTG FACILITIES, AXIAL TERMINALS
BODY DIAMETER 0.462 INCHES NOMINAL
BODY LENGTH 1.438 INCHES NOMINAL
SCHEMATIC DIAGRAM DESIGNATOR 1C NO COMMON OR GROUNDED ELECTRODE(S)
TERMINAL TYPE AND QUANTITY 2 UNINSULATED WIRE LEAD
CASE MATERIAL METAL
CASE INSULATION MATERIAL PLASTIC
RELIABILITY INDICATOR NOT ESTABLISHED
FEATURES PROVIDED HERMETICALLY SEALED CASE

Restrictions/Controls & Freight Information | NSN 5910-00-553-6495

Category Code Description
Hazardous Material Indicator CodePThere is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product
Demilitarization Code:ANon-Munitions List Item/ Non-Strategic List Item - Demilitarization not required.
Precious Metals Indicator Code:UPrecious metal type is unknown
Criticality Code:X The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application.
Category Code Description
NMF Description 061400 CONDENSERS/PARTS NOI/CAPACITORS
Less than car load rating P 77.5
Less than truck load rating P 77.5
Water commodity Code 658 unknown
Originating Activity Code XX
Air Dimension Code A Shipment is not a consolidation and does not exceed 72 inches in any dimension.
Air Commodity H Signal Corps supplies and equipment, including radio equipment and supplies, communications equipment and supplies, electrical equipment and supplies, etc.
Air Special Handling Z No special handling required.
Special Handling Code 9 unknonwn
HAZMAT
Type of Cargo Z No special type of cargo code applicable
