Product Details | FILM FIXED RESISTOR NETWORK
5905-01-544-1607 An arrangement of multiple fixed resistive elements or discrete resistors permanently encased, encapsulated, or potted together, to form an inseparable unit. The resistive elements, consisting of a thin layer of conductive material deposited on or fused to an insulating base, usually are electrically connected to each other and may be arranged in any circuit configuration. Excludes RESISTOR, FIXED (as modified); RESISTOR ASSEMBLY; RESISTOR NETWORK, FIXED-VARIABLE; and RESISTOR SET, MATCHED.
Part Alternates: 11455216-3, 5905-01-544-1607, 01-544-1607, 5905015441607, 114552163, 015441607
Electrical and Electronic Equipment Components | Resistors
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 03 OCT 2006 | 01-544-1607 | 32068 ( RESISTOR NETWORK, FIXED, FILM ) |
