NSN 5905-01-036-1204 ASC1500144, ECS060031, ERZC14DK390
Product Details | VOLTAGE SENSITIVE RESISTOR
5905-01-036-1204 A resistor specifically designed so that its ohms value decreases with increasing applied voltage over at least a portion of its rated ohmic range. See also ABSORBER, OVERVOLTAGE.
Part Alternates: ASC1500144, ECS060031, ERZC14DK390, V39ZA6, ZNRK390, 138C926H05, 2636130506, 26361-30506, 403704, 4233763, 423-3763 , 470220100396, 4702201-00396, 50372, 5266810009, 5266810-009, 0101500601, 01015-006-01, 649150, 649-150, 9592782, 959278-2, 5905-01-036-1204, 01-036-1204, 5905010361204, 010361204
Electrical and Electronic Equipment Components | Resistors
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 22 FEB 1977 | 01-036-1204 | 10194 ( RESISTOR, VOLTAGE SENSITIVE ) |
Drawings & Photos | NSN 5905-01-036-1204
Demand History | NSN 5905-01-036-1204
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 5905-01-036-1204 | 2012-12-354 | 162 | DIBBS |
| 138C926H05 | 2012-04-117 | 5 | United States |
| 5905-01-036-1204 | 2011-12-347 | 164 | DIBBS |
| 5905-01-036-1204 | 2011-06-181 | 167 | DIBBS |
Cross Reference | NSN 5905-01-036-1204
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 01015-006-01 | 59260 | RACON INC |
| 138C926H05 | 97942 | NORTHROP GRUMMAN SYSTEMS CORPORATION DIV NORTHROP GRUMMAN SYSTEMS |
| 26361-30506 | K0656 | BAE SYSTEMS (OPERATIONS) LTD |
| 26361-30506 | U6682 | SELEX ES LTD |
| 403704 | 64959 | AMERICAN TELEPHONE AND TELEGRAPH CO |
| 4702201-00396 | 06994 | OCEAN APPLIED RESEARCH CORP |
| 50372 | 04034 | GEMS SENSORS INC. |
| 5266810-009 | 53711 | NAVAL SEA SYSTEMS COMMAND |
| 649-150 | K2504 | RS COMPONENTS LIMITED |
| 959278-2 | 49956 | RAYTHEON COMPANY DBA RAYTHEON |
| ASC1500144 | Z4779 | ASC PTY LTD |
| ECS060031 | K7739 | ATMOSPHERE CONTROL INTERNATIONAL |
| ERZC14DK390 | 54473 | MATSUSHITA ELECTRIC CORP OF AMERICA M/S 7H-4 |
| V39ZA6 | 03508 | GENERAL ELECTRIC CO SEMI-CONDUCTOR PRODUCTS DEPT |
| V39ZA6 | 24446 | GENERAL ELECTRIC CO |
| ZNRK390 | 54473 | MATSUSHITA ELECTRIC CORP OF AMERICA M/S 7H-4 |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 5905-01-036-1204
Related Products | NSN 5905-01-036-1204
Technical Data | NSN 5905-01-036-1204
| Characteristic | Specifications |
|---|---|
| ELEMENT MATERIAL | METAL |
| RESISTANCE RATING AT SPECIFIED VOLTAGE | 50OHMS AT 10 VDC |
| RESISTANCE TEMP RATING | -50.0 DEG CELSIUS NOMINAL |
| OVERALL LENGTH | 1.745 INCHES MINIMUM |
| OVERALL DIAMETER | 0.636 INCHES MAXIMUM |
| OVERALL DEPTH | 0.197 INCHES MAXIMUM |
| TERMINAL QUANTITY | 2 |
| TERMINAL TYPE | WIRE LEAD |
| MOUNTING CONFIGURATION | TWO WIRE LEADS SPACED 0.054 IN. TO 0.099 IN. APART |
| SPECIAL MARKINGS | V39ZA6 |
Restrictions/Controls & Freight Information | NSN 5905-01-036-1204
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Electro-static Discharge Susceptible: | B | ESD sensitivity |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 062960 | REOSTATS/PARTS NOI |
| Less than car load rating | ||
| Less than truck load rating | P | 77.5 |
| Water commodity Code | 72D | unknown |
| Originating Activity Code | TX | Defense Supply Center Columbus Columbus, OH 43218 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | H | Signal Corps supplies and equipment, including radio equipment and supplies, communications equipment and supplies, electrical equipment and supplies, etc. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | 3 | Electrostatic Sensitive Device (ESD), subject to damage caused by electrostatic discharge. (See DoD 4500.32-R, Volume 1, Appendix A, Section I for additional information on ESD devices). |
Management | NSN 5905-01-036-1204
Air Force
Navy| Category | Code | Description |
|---|---|---|
| Budget Code | 9 | General Support DIV57X4921.070:Air Force decentrally managed expense items (ERRC XB3, XF-3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors. |
| Materiel Management Aggregation Code | EH | SX:ELECTRONIC COMPONENTS |
| Price Validation | N | The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
|
| Fund Code | SF | Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point. |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DF | Department of the Air Force |
| Service Organization | F | U.S. Air Force |
| Reparability | N | Stock Fund (except Munitions) |
| Acquisition Advice Codes | Z | INSURANCE/NUMERIC STOCKAGE OBJECTIVE ITEM # Items which may be required occasionally or intermittently, and prudence requires that a nominal quantity of materiel be stocked due to the essentiality or the lead time of the item. 1. The item is centrally managed, stocked, and issued. 2. Requisitions will be submitted in accordance with IMM/Service requisitioning procedures. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 9B | Navy-owned stocks of DLA material Naval Inventory Control Point, Mechanicsburg |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Acquisition Advice Codes | Z | INSURANCE/NUMERIC STOCKAGE OBJECTIVE ITEM # Items which may be required occasionally or intermittently, and prudence requires that a nominal quantity of materiel be stocked due to the essentiality or the lead time of the item. 1. The item is centrally managed, stocked, and issued. 2. Requisitions will be submitted in accordance with IMM/Service requisitioning procedures. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
