NSN 5905-00-570-5874 SCC18907, 21212, 00-570-5874
Product Details | RESISTOR ASSEMBLY
5905-00-570-5874 Two or more individual fixed, variable, thermal, or adjustable resistors on a common mounting or mounted on each other. The resistors must be separable and each must be capable of functioning in accordance with its applicable item name. For variable resistors mounted in tandem with a common or dual concentric shaft, see RESISTOR, VARIABLE (as modified) and ATTENUATOR, VARIABLE. For inseparable resistors permanently cased, sealed or potted together to form a multisection unit, see RESISTOR ASSORTMENT; RESISTOR SET, MATCHED; and items which have wire leads temporarily twisted together, or are otherwise physically attached solely for convenience in handling or shipping.
Part Alternates: SCC18907, 21212, 5905-00-570-5874, 00-570-5874, 5905005705874, 005705874
Electrical and Electronic Equipment Components | Resistors
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 00-570-5874 | 00487 ( RESISTOR ASSEMBLY ) |
Drawings & Photos | NSN 5905-00-570-5874
Demand History | NSN 5905-00-570-5874
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 21212 | 2024-07-183 | 61 | Japan |
| 21212 | 2022-09-250 | 100 | us |
| 21212 | 2022-09-250 | 200 | us |
| 21212 | 2017-04-101 | 10 | Canada |
| 21212 | 2013-06-177 | 400 | United States |
| 21212 | 2011-06-158 | 100 | United States |
| 21212 | 2010-09-259 | 100 | United States |
| 21212 | 2009-11-319 | 2200 | US |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 5905-00-570-5874
Technical Data | NSN 5905-00-570-5874
| Characteristic | Specifications |
|---|---|
| ASSEMBLY CONSTRUCTION METHOD | MOUNTED ON TERMINAL BOARD |
| BOARD MATERIAL | PLASTIC |
| LENGTH | 10.750 INCHES NOMINAL |
| WIDTH | 1.500 INCHES NOMINAL |
| THICKNESS | 0.125 INCHES NOMINAL |
| COMPONENT RELATIONSHIP | NOT MATCHED |
| COMPONENT QUANTITY | 12 |
| COMPONENT NAME | FIXED COMPOSITION RESISTOR |
| COMPONENT CONTROLLING AGENCY | INTERNATIONAL RESISTANCE CO. |
| COMPONENT IDENTIFYING NUMBER | BTB TYPE NO. |
| ELECTRICAL RESISTANCE | 2.500 KILOHMS |
| RESISTANCE TOLERANCE IN PERCENT | -5.00 TO 5.00 |
| RESISTOR POWER DISSIPATION RATING IN WATTS | 2.000 |
| MOUNTING METHOD | BRACKET |
| MOUNTING CONFIGURATION | FOUR MTG BRACKETS ALONG ONE EDGE SPACED 3.500 IN. C TO C |
| MANUFACTURERS CODE | 80063 |
| DESIGN CONTROL REFERENCE | SCC18907 |
Restrictions/Controls & Freight Information | NSN 5905-00-570-5874
| Category | Code | Description |
|---|---|---|
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Category | Code | Description |
|---|---|---|
| No Freight Information | ||
