NSN 5905-00-552-3524 MS35836463, MS35836-463, A2805174
Product Details | FILM FIXED RESISTOR
5905-00-552-3524 A resistor whose ohmic value cannot be adjusted or varied. The resistance element consists of either a thin layer of conductive material, containing either binders or insulating materials, deposited on an insulated form; or an alloy of metal and ceramic materials, usually fused to an insulated form. Opposition to the flow of current is an inherent property of the materials used and is manifest by the heat dissipation in the resistor. See also ATTENUATOR, FIXED and RESISTOR, FIXED, COMPOSITION. Excludes carbon composition type resistors.
Part Alternates: MS35836463, MS35836-463, A2805174, A28051-74 , MILR105093, MILR10509-3, RN70B1622F, 184041, 1840-41 , 5146219 , 5182526, 5182544 , 5182545, 8718921717, 871-8921717 , 8921717 , 5905-00-552-3524, 00-552-3524, 5905005523524, 005523524
Electrical and Electronic Equipment Components | Resistors
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 01 JAN 1963 | 00-552-3524 | 05311 ( RESISTOR, FIXED, FILM ) |
Drawings & Photos | NSN 5905-00-552-3524
Demand History | NSN 5905-00-552-3524
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 5905-00-552-3524 | 2024-04-115 | 4 | Thailand |
| 184041 | 2013-09-246 | 1 | ZA |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 5905-00-552-3524
Related Products | NSN 5905-00-552-3524
Technical Data | NSN 5905-00-552-3524
| Characteristic | Specifications |
|---|---|
| ELECTRICAL RESISTANCE | 16.200 KILOHMS |
| RESISTANCE TOLERANCE IN PERCENT | -1.000 TO 1.000 |
| POWER DISSIPATION RATING IN WATTS | 0.500 FREE AIR |
| AMBIENT TEMP IN DEG CELSIUS AT FULL RATED POWER | 40.0 |
| AMBIENT TEMP IN DEG CELSIUS AT ZERO PERCENT RATED POWER | 120.0 |
| TEMP COEFFICIENT OF RESISTANCE IN PPM PER DEG CELSIUS | -500.0 TO 500.0 |
| TEMP RANGE OF TEMP COEFFICIENT IN DEG CELSIUS | -55.0 TO 105.0 |
| INCLOSURE METHOD | ENCAPSULATED |
| STYLE DESIGNATOR | 14 AXIAL TERMINAL EACH END |
| BODY DIAMETER | 0.250 INCHES NOMINAL |
| BODY LENGTH | 0.750 INCHES NOMINAL |
| TERMINAL TYPE | WIRE LEAD |
| TEST DATA DOCUMENT | 81349-MILR10509 SPECIFICATION |
| MANUFACTURERS CODE | 81349 |
| NON-DEFINITIVE GOVERNMENT SPEC/STD REFERENCE | MILR10509-3 |
| MANUFACTURERS CODE | 81349 |
| DEFINITIVE GOVERNMENT SPEC/STD REFERENCE | RN70B1622F |
Restrictions/Controls & Freight Information | NSN 5905-00-552-3524
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Electro-static Discharge Susceptible: | A | No known Electrostatic Discharge (ESD) or Electromagnetic Interference (EMI) sensitivity |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 061300 | CIRCUIT BREAKER/SWITCH NOI |
| Less than car load rating | ||
| Less than truck load rating | P | 77.5 |
| Water commodity Code | 72D | unknown |
| Originating Activity Code | XX | |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | H | Signal Corps supplies and equipment, including radio equipment and supplies, communications equipment and supplies, electrical equipment and supplies, etc. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
