Product Details | DIGITAL DATA COUPLER

5895-01-417-5459 An item which provides a means of transferring digital data between two or more comparators, peripherals or the like.20358950037Miscellaneous Communication Equipment66250070Electrical and Electronic Properties Measuring and Testing Instruments70250036ADP Input/Output and Storage Devices

Part Alternates: DBC3430BJ77, DBC-3430-BJ77, 5895-01-417-5459, 01-417-5459, 5895014175459, 014175459

Communication, Detection, and Coherent Radiation Equipment | Miscellaneous Communication Equipment

Supply Group (FSG) NSN Assign. NIIN
58 09 AUG 1995 01-417-5459

Drawings & Photos | NSN 5895-01-417-5459


Demand History | NSN 5895-01-417-5459

Part Number Request Date QTY Origin
5895-01-417-5459 2018-01-16 1 DIBBS
5895-01-417-5459 2017-02-45 1 DIBBS
5895-01-417-5459 2011-06-164 4 DIBBS
5895-01-417-5459 2009-12-351 6 DIBBS
5895-01-417-5459 2009-11-308 13 DIBBS
5895-01-417-5459 2009-08-219 2 United States
5895-01-417-5459 2009-07-209 2 DIBBS
5895-01-417-5459 2009-04-117 2 DIBBS

Cross Reference | NSN 5895-01-417-5459

Part Number Cage Code Manufacturer
DBC-3430-BJ77 90095 PULSE ELECTRONICS CORPORATION DBA PULSE COMPONENTS DIVISION

Request a Quote

What Our Customers Say

Compare

NSNs for Compare ( up to 4 ): Add 5895-01-417-5459

Technical Data | NSN 5895-01-417-5459

Characteristic Specifications
COUPLING METHOD TRANSFORMER
TUNING TYPE FIXED
TERMINAL QUANTITY 3
TERMINAL TYPE COAXIAL JACKS
OVERALL LENGTH 2.500 INCHES NOMINAL
OVERALL WIDTH 1.910 INCHES MAXIMUM
OVERALL HEIGHT 1.100 INCHES MAXIMUM
SPECIAL FEATURES 3 LUG TYPE COAXIAL JACKS
III END ITEM IDENTIFICATION AC-130U MOD
III UNPACKAGED UNIT WEIGHT 100.000 GRAMS
III FUNCTIONAL DESCRIPTION 3 PORTS (2 BUS/ 1 STUB)
MANUFACTURERS CODE 90095
DESIGN CONTROL REFERENCE DBC-3430-BJ77
