NSN 5895-01-326-7223 D500025502101, D-500-0255-021-01, 01-326-7223
Product Details | MULTIPLEXER
5895-01-326-7223 An item designed to combine two or more simultaneous intelligence signals for transmission over a single transmission facility. Includes both time division and frequency division types or combinations thereof. Does not include the transmission facilities.
Part Alternates: D500025502101, D-500-0255-021-01, 5895-01-326-7223, 01-326-7223, 5895013267223, 013267223
Communication, Detection, and Coherent Radiation Equipment | Miscellaneous Communication Equipment
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 58 | 28 SEP 1990 | 01-326-7223 | 00222 ( MULTIPLEXER ) |
Drawings & Photos | NSN 5895-01-326-7223
Demand History | NSN 5895-01-326-7223
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| D-500-0255-021-01CS252 | 2022-03-82 | 6 | DIBBS |
| NH16951-1 | 2022-03-82 | 6 | DIBBS |
| D-500-0255-021-01CS252 | 2020-04-111 | 5 | DIBBS |
| NH16951-1 | 2020-04-111 | 5 | DIBBS |
| D-500-0255-021-01CS252 | 2020-04-98 | 5 | DIBBS |
| NH16951-1 | 2020-04-98 | 5 | DIBBS |
| D-500-0255-021-01CS252 | 2020-01-21 | 9 | DIBBS |
| NH16951-1 | 2020-01-21 | 9 | DIBBS |
| D-500-0255-021-01CS252 | 2020-01-09 | 9 | DIBBS |
| NH16951-1 | 2020-01-09 | 9 | DIBBS |
| 5895-01-326-7223 | 2017-07-206 | 12 | United States |
| 5895-01-326-7223 | 2017-07-194 | 17 | United States |
| 5895-01-326-7223 | 2017-05-137 | 17 | DIBBS |
| 5895-01-326-7223 | 2017-05-129 | 17 | DIBBS |
| 5895-01-326-7223 | 2017-01-26 | 12 | DIBBS |
| 5895-01-326-7223 | 2017-01-23 | 9 | DIBBS |
Cross Reference | NSN 5895-01-326-7223
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| D-500-0255-021-01 | 06090 | TYCO ELECTRONICS CORPORATION |
