NSN 5895-00-501-0890 41945, 7012810G4, 00-501-0890
Product Details | DUPLEXER SUBASSEMBLY
5895-00-501-0890 Two or more different types of items having a common mounting or mounted on each other which together form a portion of a duplexer but which in itself is not a complete functioning item and cannot be assigned a more definite item name.
Part Alternates: 41945, 7012810G4, 5895-00-501-0890, 00-501-0890, 5895005010890, 005010890
Communication, Detection, and Coherent Radiation Equipment | Miscellaneous Communication Equipment
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 58 | 01 JAN 1963 | 00-501-0890 | 17052 ( DUPLEXER SUBASSEMBLY ) |
Drawings & Photos | NSN 5895-00-501-0890
Demand History | NSN 5895-00-501-0890
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 41945 | 2011-01-28 | 2 |
Cross Reference | NSN 5895-00-501-0890
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 41945 | 28916 | ATLANTIC MICROWAVE CORPORATION DIV COBHAM ELECTRONIC SYSTEMS |
| 41945 | 66544 | CONTINENTAL MICROWAVE AND TOOL CO., INC. |
| 41945 | 80006 | LITTON SYSTEMS INC AIRTRON DIV |
| 7012810G4 | 24446 | GENERAL ELECTRIC CO |
| 7012810G4 | 99142 | GENERAL ELECTRIC CO INDUSTRIAL ELECTRONICS DIVISION |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 5895-00-501-0890
Technical Data | NSN 5895-00-501-0890
| Characteristic | Specifications |
|---|---|
| OVERALL LENGTH | 10.375 INCHES NOMINAL |
| OVERALL HEIGHT | 2.875 INCHES NOMINAL |
| OVERALL WIDTH | 3.000 INCHES NOMINAL |
| SPECIAL FEATURES | BOLT AND FLANGE MTD;DUPLEXER SECTION 1,ATR TUBE 1,TR TUBE 1,FLEXIBLE WAVEGUIDE SECTION 1;JETDS NAME:RADAR SET;JETDS TYPE NO. AN/SPN-12;FOUR NO. 8/0.164 IN./-32 THD MTG HOLES ON 1.220 X 1.280 IN. MTG CTRS |
| MANUFACTURERS CODE | 66544 |
| DESIGN CONTROL REFERENCE | 41945 |
Restrictions/Controls & Freight Information | NSN 5895-00-501-0890
| Category | Code | Description |
|---|---|---|
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | C | Munitions List Item or Commerce Control List Item. Demilitarization required. Remove and/or demilitarize installed key point(s) as prescribed in the Defense Demilitarization Manual, or lethal parts, components and accessories. |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
| Category | Code | Description |
|---|---|---|
| NMF Description | 061700 | ELEC APPLIANCES/INSTRUMENTS NOI |
| Less than car load rating | P | 77.5 |
| Less than truck load rating | W | Rating Variable |
| Water commodity Code | 72D | unknown |
| Originating Activity Code | XX | |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | H | Signal Corps supplies and equipment, including radio equipment and supplies, communications equipment and supplies, electrical equipment and supplies, etc. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | Z | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
