NSN 5840-01-188-7091 78041910, 7804-1910, 7804-1910-1
Product Details | RADAR SET SUBASSEMBLY
5840-01-188-7091 Two or more different types of items, having a common mounting or mounted on each other, which together form a portion of a radar set, but, which in itself is not a complete functioning item and cannot be assigned a more definite item name.20512700040Aircraft Gunnery Fire Control Components12800040Aircraft Bombing Fire Control Components12850045Fire Control Radar Equipment, except Airborne58400032Radar Equipment, Except Airborne58410025Radar Equipment, Airborne
Part Alternates: 78041910, 7804-1910, 7804-1910-1, 5840-01-188-7091, 01-188-7091, 5840011887091, 011887091, 780419101
Communication, Detection, and Coherent Radiation Equipment | Radar Equipment, Except Airborne
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 58 | 07 SEP 1984 | 01-188-7091 | 19057 ( RADAR SET SUBASSEMBLY ) |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 5840-01-188-7091
Technical Data | NSN 5840-01-188-7091
| Characteristic | Specifications |
|---|---|
| END ITEM IDENTIFICATION | RADAR BOMB SCORING SET,SEEK SCORE,AN/TPQ-43 |
| OVERALL LENGTH | 3.875 INCHES NOMINAL |
| OVERALL HEIGHT | 3.000 INCHES NOMINAL |
| OVERALL WIDTH | 2.750 INCHES NOMINAL |
| SPECIAL FEATURES | ITEM INCLUDES BASE 1, SHAFT ASSY 1, COVER 1, GEAR 5, HUB & MOTOR 1, LIMIT STOP 1, HOUSING 1, POTENTIOMETER 1, BEARING 2, RING 3; USED AS FREQUENCY METER; ITEM IS CALLED GEAR TRAIN ASSY |
| MANUFACTURERS CODE | 12115 |
| DESIGN CONTROL REFERENCE | 7804-1910-1 |
Restrictions/Controls & Freight Information | NSN 5840-01-188-7091
| Category | Code | Description |
|---|---|---|
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | D | Munitions List Item or Commerce Control List Item. Demilitarization required. Total destruction of the item and components so as to preclude restoration or repair to a usable condition by melting, cutting, tearing, scratching, crushing, breaking, punching, neutralizing, etc. (As an alternate, burial or deep water dumping may be used when coordinated with the DoD Demilitarization Program Office.) |
| Electro-static Discharge Susceptible: | A | No known Electrostatic Discharge (ESD) or Electromagnetic Interference (EMI) sensitivity |
| Precious Metals Indicator Code: | C | Item contains two or more precious metals |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
| Category | Code | Description |
|---|---|---|
| NMF Description | 095190 | HARDWARE, NOI |
| Less than car load rating | Q | 70 |
| Less than truck load rating | W | Rating Variable |
| Water commodity Code | 713 | unknown |
| Originating Activity Code | TA | Sacramento Air Logistics Center McClellan AFB, CA 95652-5609 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | ||
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | Z | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
