NSN 5840-00-892-3341 AM1780/VRC , AM1780VRC , ANFPS20L
Product Details | RADAR SET
5840-00-892-3341 A fixed number of components and/or items, not all having the same basic name, which are required for the performance of a complete specific operational function, that propagate into space and utilize reflected portions of electromagnetic waves for such purposes as detecting the presence and/or determining the location of distant objects, projectile velocity measurements, terrain clearance measurements, bomb directing measurement, and the like. See also RADAR SET, SEMITRAILER MOUNTED.20612700040Aircraft Gunnery Fire Control Components12800040Aircraft Bombing Fire Control Components12850045Fire Control Radar Equipment, except Airborne14300037Guided Missile Remote Control Systems58400032Radar Equipment, Except Airborne58410025Radar Equipment, Airborne
Part Alternates: AM1780/VRC , AM1780VRC , ANFPS20L, SCDL415275 , EL500, MILA55129, 2510004062 , 818214 , 5840-00-892-3341, 00-892-3341, 5820008923342, 5840008923341, 008923341
Communication, Detection, and Coherent Radiation Equipment | Radar Equipment, Except Airborne
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 58 | 01 JAN 1960 | 00-892-3341 | 19159 ( RADAR SET ) |
Drawings & Photos | NSN 5840-00-892-3341
Demand History | NSN 5840-00-892-3341
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| AM1780VRC | 2009-12-362 | 10 | US |
| SCDL415275 | 2008-01-24 | 1 | us |
| AM1780VRC | 2007-06-179 | 50 | France |
| AM1780VRC | 2007-03-81 | 25 | FX |
| AM1780VRC | 2007-03-81 | 50 | FX |
| AM1780VRC | 2007-03-81 | 70 | FX |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 5840-00-892-3341
Related Products | NSN 5840-00-892-3341
Technical Data | NSN 5840-00-892-3341
| Characteristic | Specifications |
|---|---|
| TRANSMITTED SIGNAL FREQUENCY RATING | 1250.0 MEGAHERTZ MINIMUM AND 1350.0 MEGAHERTZ MAXIMUM |
| TRANSMITTER CHANNEL QUANTITY | 2 |
| RECEIVED SIGNAL FREQUENCY RATING | 1250.0 MEGAHERTZ MINIMUM AND 1350.0 MEGAHERTZ MAXIMUM |
| RECEIVER CHANNEL QUANTITY | 2 |
| ELECTRICAL POWER SOURCE RELATIONSHIP | OPERATING |
| AC VOLTAGE RATING | 120.0 VOLTS MINIMUM 1ST OPERATING POWER RQMT 208.0 VOLTS MAXIMUM 1ST OPERATING POWER RQMT |
| FREQUENCY RATING | 60.0 HERTZ NOMINAL |
| PHASE | THREE |
| COMPONENT DOCUMENT ORIGIN | GOVERNMENT |
| DOCUMENT TYPE | NOMENCLATURE CARD |
| DOCUMENT IDENTIFICATION | AN/FPS20L |
| COMPONENT DOCUMENT PAGE NUMBER | 6493-17 |
| MANUFACTURERS CODE | 80058 |
| DESIGN CONTROL REFERENCE | ANFPS20L |
