NSN 5830-01-092-4743 LS-614A/STC-1, LS614ASTC1, 66409000
Product Details | INTERCOMMUNICATION STATION
5830-01-092-4743 An item which may provide two-way amplified voice communications when connected to one or more like stations directly or via intermediate control equipment; includes loudspeaker (which may be used as a loudspeaker or microphone), signalling devices, amplifier and station selector switches. May include separate microphone, earphone, handset or headset. See also, TELEPHONE CONNECTING STATION.20258300062Intercommunication and Public Address Systems, Except Airborne58310055Intercommunication and Public Address Systems, Airborne
Part Alternates: LS-614A/STC-1, LS614ASTC1, 66409000, 66409-000, 5830-01-092-4743, 01-092-4743, 5830010924743, 010924743
Communication, Detection, and Coherent Radiation Equipment | Intercommunication and Public Address Systems, Except Airborne
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 58 | 26 MAR 1980 | 01-092-4743 | 03570 ( INTERCOMMUNICATION STATION ) |
Demand History | NSN 5830-01-092-4743
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 5830-01-092-4743 | 2022-03-29 | 1 | United States |
| 66409000 | 2021-10-05 | 8 | United States |
| 5830-01-092-4743 | 2018-06-27 | 1 | United States |
| 5830-01-092-4743 | 2018-03-26 | 2 | United States |
| 5830-01-092-4743 | 2018-03-23 | 2 | United States |
| 5830-01-092-4743 | 2017-08-17 | 12 | United States |
| 5830-01-092-4743 | 2016-03-28 | 10 | United States |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 5830-01-092-4743
Related Products | NSN 5830-01-092-4743
Technical Data | NSN 5830-01-092-4743
| Characteristic | Specifications |
|---|---|
| ELECTRICAL POWER SOURCE RELATIONSHIP | OPERATING |
| DC VOLTAGE RATING | 10.6 VOLTS NOMINAL |
| INTERNAL BATTERY ACCOMMODATION | NOT INCLUDED |
| JOINT ELECTRONICS TYPE DESIGNATION SYSTEM ITEM NAME | INTERCOMMUNICATION STATION |
| JOINT ELECTRONICS TYPE DESIGNATION SYSTEM ITEM TYPE NUMBER | LS-614A/STC-1 |
| TRANSDUCER TYPE | LOUDSPEAKER |
| TRANSDUCER QUANTITY | 1 |
| ELECTRICAL TRANSMISSION TYPE | WIRE |
| AMPLIFIER | INCLUDED |
| USAGE DESIGN | INDOOR |
| SWITCH POSITION QUANTITY | 3 |
| ALL STATION POSITION | NOT INCLUDED |
| SPECIAL FEATURES | ITEMS ARE BEING CODED AS CRITICAL TO INSURE SOURCE INSPECTION WILL BE PERFORMED AT THE POINT OF MANUFACTURE, PRIOR TO MATERIAL RECEIPT BY THE US NAVY OR OTHER DOD COMPONENTS. THESE ITEMS ARE PIECE PARTS OR END ITEMS IN SUPPORT OF VITAL MILITARY HARDWARE NECESSARY TO SUSTAIN THE SUCCESSFUL MISSION OF THE SHIPS, SUBMARINES, AND SHORE STATIONS OF THE US NAVY. CRITICAL FEATURES INCLUDING, BUT NOT LIMITED TO, DIMENSIONS, TOLERANCES/CLEARANCES, ELECTRONIC CHARACTERISTICS, AND METALLURGICAL PROPERTIES WILL BESPECIFIED FOR GOVERNMENT Q AR (QUALITY ASSURANCE REPRESENTATIVES) TO INSURE THE HIGHEST POSSIBLE DEGREE OF QUALITY AND RELIABILITY OF THESE PARTS BEING DELIVERED UNDER NAVICP CONTRACTS |
| CRITICALITY CODE JUSTIFICATION | FEAT |
| MANUFACTURERS CODE | 12763 |
| DESIGN CONTROL REFERENCE | 66409-000 |
Restrictions/Controls & Freight Information | NSN 5830-01-092-4743
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | Y | The item does not have a nuclear hardened feature but does have other critical feature(s) such as tolerance, fit restriction or application. |
| Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
| Category | Code | Description |
|---|---|---|
| NMF Description | 062820 | RADIO/TV TRANSMIT/RECEIVE SETS |
| Less than car load rating | M | 85 |
| Less than truck load rating | W | Rating Variable |
| Water commodity Code | 72D | unknown |
| Originating Activity Code | HD | Naval Inventory Control Point Mechanicsburg, PA 17055-0788 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | H | Signal Corps supplies and equipment, including radio equipment and supplies, communications equipment and supplies, electrical equipment and supplies, etc. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 5830-01-092-4743
Navy| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 7H | Depot level reparable shipboard and base equipment, assemblies, components and repair parts related to Naval Sea Systems Command equipment Naval Inventory Control Point, Mechanicsburg |
| Special Material ID | GL | Gold Disk Repair Capable NSN |
| Special Material Content | 9 | Non-Hazardous or Non-Sensitive Item, does not require hazardous or special handling, packaging or precautions |
| Source of Supply | NRP | NAVICP-ERP 700 Robbins Avenue Philadelphia, PA 19111-5098 |
| Agency | DN | Department of the Navy |
| Service Organization | L | Lead Service - 22 (Repairable) |
| Reparability | E | (1) IRAM Program Intensive Management Reparables (2) Material (expendable ordnance) Requiring Lot and Serial Number Control but which is Reported by Serial Number Only |
| Acquisition Advice Codes | H | DIRECT DELIVERY UNDER A CENTRAL CONTRACT # (VENDOR STOCKED) Issue, transfer or shipment is not subject to specialized controls other than those imposed by IMM/Service/Agency supply policy. 1. The item is centrally managed and procured. 2. Normal issue is by direct shipment from the vendor to the user at the order of the ICP or IMM. However, orders may be shipped from stock by ICP or IMM distribution facilities when the vendor's minimum order quantity is not met, or when stocks are being drawn down. 3. Requisitions and fund citations will be submitted in accordance with IMM/Service/Agency Requisitioning Procedures. 4. Generally delivery will be made within applicable Service/Agency guidelines addressing customer required timeframe. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
