NSN 5826-00-505-3092 ID387ARN, 72041A4A1, 7204-1A4A1

Product Details | COURSE INDICATOR

5826-00-505-3092 An indicator that displays the angular value, measured clockwise, between true north and a line connecting the points of origin and destination over which an aircraft, ship or ground vehicle travels.20712800040Aircraft Bombing Fire Control Components58260036Radio Navigation Equipment, Airborne58400032Radar Equipment, Except Airborne6320000066050024Navigational Instruments66100018Flight Instruments69300026Operation Training Devices

Part Alternates: ID387ARN, 72041A4A1, 7204-1A4A1, 5826-00-505-3092, 00-505-3092, 5826005053092, 005053092

Communication, Detection, and Coherent Radiation Equipment | Radio Navigation Equipment, Airborne

Supply Group (FSG)	NSN Assign.	NIIN	Item Name Code (INC)
58	01 JAN 1963	00-505-3092	19647 ( INDICATOR, COURSE )

Drawings & Photos | NSN 5826-00-505-3092

Part Number	Request Date	QTY	Origin
ID387ARN	2016-02-33	1	United States
ID387ARN	2016-02-33	2	United States
ID387ARN	2016-01-13	3	US
ID387ARN	2015-08-218	1	United States
ID387ARN	2014-07-199	2	United States
ID387ARN	2013-04-107	3	United States
ID387ARN	2013-04-107	3	United States

Cross Reference | NSN 5826-00-505-3092

Part Number	Cage Code	Manufacturer
7204-1A4A1	19315	HONEYWELL INTL INC DEFENSE AVIONICS SYSTEMS FORMER BENDIX NAVIGATION AND
7204-1A4A1	55972	HONEYWELL INTL INC DEFENSE AVIONICS SYSTEMS
7204-1A4A1	96774	HONEYWELL INTERNATIONAL INC. DBA HONEYWELL
ID387ARN	80058	JOINT ELECTRONICS TYPE DESIGNATION SYSTEM
