Product Details | RADIO RECEIVER-TRANSMITTER

5820-01-470-3522 A single component capable of performing the functions of a RECEIVER, RADIO; and TRANSMITTER, RADIO.20358200061Radio and Television Communication Equipment, Except Airborne58210054Radio and Television Communication Equipment, Airborne

Part Alternates: 31000, 5820-01-470-3522, 01-470-3522, 5820014703522, 014703522

Communication, Detection, and Coherent Radiation Equipment | Radio and Television Communication Equipment, Except Airborne

Supply Group (FSG) NSN Assign. NIIN
58 15 DEC 1999 01-470-3522

Drawings & Photos | NSN 5820-01-470-3522


Demand History | NSN 5820-01-470-3522

Part Number Request Date QTY Origin
31000 2019-06-169 1 US
31000 2019-03-77 4 NG

Cross Reference | NSN 5820-01-470-3522

Part Number Cage Code Manufacturer
31000 61376 WESTERN MULTIPLEX CORP

Request a Quote

What Our Customers Say

Compare

NSNs for Compare ( up to 4 ): Add 5820-01-470-3522

Technical Data | NSN 5820-01-470-3522

Characteristic Specifications
ELECTRICAL POWER SOURCE RELATIONSHIP OPERATING
AC VOLTAGE RATING 100.0 VOLTS MINIMUM AND 250.0 VOLTS MAXIMUM
FREQUENCY RATING 5725.0 MEGAHERTZ MINIMUM AND 5850.0 MEGAHERTZ MAXIMUM
DC VOLTAGE RATING 20.0 VOLTS MINIMUM AND 63.0 VOLTS MAXIMUM
OVERALL LENGTH 17.200 INCHES NOMINAL
OVERALL WIDTH 3.500 INCHES NOMINAL
OVERALL DEPTH 14.500 INCHES NOMINAL
OUTPUT FREQUENCY RATING 5735.00 MEGAHERTZ MINIMUM AND 5840.0 MEGAHERTZ MAXIMUM

Restrictions/Controls & Freight Information | NSN 5820-01-470-3522

Category Code Description
Hazardous Material Indicator CodePThere is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product
Demilitarization Code:DMunitions List Item or Commerce Control List Item. Demilitarization required. Total destruction of the item and components so as to preclude restoration or repair to a usable condition by melting, cutting, tearing, scratching, crushing, breaking, punching, neutralizing, etc. (As an alternate, burial or deep water dumping may be used when coordinated with the DoD Demilitarization Program Office.)
Electro-static Discharge Susceptible:ANo known Electrostatic Discharge (ESD) or Electromagnetic Interference (EMI) sensitivity
Precious Metals Indicator Code:AItem does not contain precious metal
Criticality Code:X The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application.
Automatic Data Processing Equipment:0Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9)
Category Code Description
No Freight Information
