NSN 5820-01-234-0747 GVG100N, GVG100-N, GVG110N
Product Details | AUDIO-VIDEO SWITCHING UNIT
5820-01-234-0747 An item that electrically and/or mechanically switches audio and/or video signals. It is designed to select audio/video inputs to be applied to specific outputs via manual control or remote control units. It allows signals to be switched to specific equipment such as monitors, recorders, editors and the like. It may be rack mounted or a stand alone unit.20358200061Radio and Television Communication Equipment, Except Airborne58210054Radio and Television Communication Equipment, Airborne58360041Video Recording and Reproducing Equipment
Part Alternates: GVG100N, GVG100-N, GVG110N, GVG110-N, 5820-01-234-0747, 01-234-0747, 5820012340747, 012340747
Communication, Detection, and Coherent Radiation Equipment | Radio and Television Communication Equipment, Except Airborne
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 58 | 06 JUN 1986 | 01-234-0747 | 41999 ( SWITCHING UNIT, AUDIO-VIDEO ) |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 5820-01-234-0747
Technical Data | NSN 5820-01-234-0747
| Characteristic | Specifications |
|---|---|
| CURRENT TYPE | DC |
| VOLTAGE IN VOLTS | 260.0 |
| III FUNCTIONAL DESCRIPTION | CAPABILITY OF OFF-LINE EDITING DURING STUDIO PRODUCTIONS |
| MANUFACTURERS CODE | 32760 |
| DESIGN CONTROL REFERENCE | GVG110-N |
Restrictions/Controls & Freight Information | NSN 5820-01-234-0747
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | P | There is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product |
| Demilitarization Code: | Q | Strategic List Item (SLI). Demilitarization not required. SLI are non-MLI(Munitions List Items) controlled by the U.S. Dept. of Commerce through the Export Administration Regulations (EAR) and indicated on the Commerce Control List (CCL). Each CCL entry is preceded by a four-digit Export Control Commerce Control List Item (CCLI) – MUT to the point of scrap required outside the United States. Inside the United States, MUT is required when the DEMIL integrity code (IC) is “3” and MUT is not required when the DEMIL IC is “6.” |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Electro-static Discharge Susceptible: | A | No known Electrostatic Discharge (ESD) or Electromagnetic Interference (EMI) sensitivity |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
| Category | Code | Description |
|---|---|---|
| NMF Description | 063035 | SETS RADIO/TV AND RELATED ARTICLES |
| Less than car load rating | M | 85 |
| Less than truck load rating | G | 125.0 |
| Water commodity Code | 738 | unknown |
| Originating Activity Code | TA | Sacramento Air Logistics Center McClellan AFB, CA 95652-5609 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | H | Signal Corps supplies and equipment, including radio equipment and supplies, communications equipment and supplies, electrical equipment and supplies, etc. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | 3 | Electrostatic Sensitive Device (ESD), subject to damage caused by electrostatic discharge. (See DoD 4500.32-R, Volume 1, Appendix A, Section I for additional information on ESD devices). |
