NSN 5640-01-383-7815 DODI24688, DOD-I-24688, DOD-I-24688 TY2CL2
Product Details | SOUND CONTROLLING BOARD
5640-01-383-7815 A light, rigid item composed of one or more kinds of granule and/or fiber with binder added, compressed to the desired density, and dried. It may be with or without surface coating and/or perforations or voids to be exposed to the noise area to entrap and dissipate sound energy, and is rated for this use. It is provided in lengths greater than 36 inches (914.4 mm).
Part Alternates: DODI24688, DOD-I-24688, DOD-I-24688 TY2CL2, DODI24688TY2CL2, 5640-01-383-7815, 01-383-7815, 5640013837815, 013837815
Construction and Building Materials | Wallboard, Building Paper, and Thermal Insulation Materials
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 56 | 02 DEC 1993 | 01-383-7815 | 20228 ( SOUND CONTROLLING BOARD ) |
Demand History | NSN 5640-01-383-7815
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 5640-01-383-7815 | 2017-09-256 | 18 | United States |
| 5640-01-383-7815 | 2017-07-207 | 20 | United States |
| 5640-01-383-7815 | 2017-06-179 | 18 | United States |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 5640-01-383-7815
Technical Data | NSN 5640-01-383-7815
| Characteristic | Specifications |
|---|---|
| BASIC MATERIAL | POLYAMIDE FIBER |
| OVERALL THICKNESS | 1.000 INCHES NOMINAL |
| COVERAGE WIDTH | 24.000 INCHES NOMINAL |
| OVERALL WIDTH | 24.000 INCHES NOMINAL |
| COVERAGE LENGTH | 48.000 INCHES NOMINAL |
| OVERALL LENGTH | 48.000 INCHES NOMINAL |
| NOISE REDUCTION COEFFICIENT RATING | 0.25 MINIMUM AND 0.90 MAXIMUM |
| NONDEFINITIVE SPEC/STD DATA | 2 TYPE AND 2 CLASS |
| MANUFACTURERS CODE | 81349 |
| NON-DEFINITIVE GOVERNMENT SPEC/STD REFERENCE | DOD-I-24688 |
Restrictions/Controls & Freight Information | NSN 5640-01-383-7815
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | P | There is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| No Freight Information | ||
Management | NSN 5640-01-383-7815
Navy| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 9Q | Navy-owned stocks of items accepted by the General Services Administration for support of Navy requirements Naval Inventory Control Point, Mechanicsburg |
| Source of Supply | GSA | General Services Administration Washington, D.C. 20406 |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Acquisition Advice Codes | J | NOT STOCKED, CENTRALLY PROCURED # (NON-STOCKED ITEMS) IMM/Service centrally managed but not stocked item. Procurement will be initiated only after receipt of a requisition. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
