Product Details | KEYED LOCK RING

5365-01-497-0136 A locking device with two keys spaced approximately 180 degrees center to center and protruding from the seating surface of the ring. When installed the keys mate with companion keyways in the external threads of screw thread inserts, locked-in studs, or similar type items, and cut through sufficient threads of the parent material tapped hole to provide a positive lock between the threaded bodies.

Part Alternates: 600418, 5365-01-497-0136, 01-497-0136, 5365014970136, 014970136

Hardware and Abrasives | Bushings, Rings, Shims, and Spacers

Supply Group (FSG) NSN Assign. NIIN
53 06 MAY 2002 01-497-0136

Cross Reference | NSN 5365-01-497-0136

Part Number Cage Code Manufacturer
600418 21439 ENGINEERED ARRESTING SYSTEMS CORPORATION

Request a Quote

What Our Customers Say

Compare

NSNs for Compare ( up to 4 ): Add 5365-01-497-0136

Technical Data | NSN 5365-01-497-0136

Characteristic Specifications
SPECIAL FEATURES NEXT HIGHER ASSEMBLY, PART NUMBER 010005
III END ITEM IDENTIFICATION STANCHION MK-4 ASSEMBLY, ENGINEERED ARRESTING SYSTEMS CORP.

Restrictions/Controls & Freight Information | NSN 5365-01-497-0136

Category Code Description
Hazardous Material Indicator CodeNThere is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials
Demilitarization Code:ANon-Munitions List Item/ Non-Strategic List Item - Demilitarization not required.
Electro-static Discharge Susceptible:ANo known Electrostatic Discharge (ESD) or Electromagnetic Interference (EMI) sensitivity
Precious Metals Indicator Code:AItem does not contain precious metal
Criticality Code:X The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application.
Automatic Data Processing Equipment:0Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9)
Category Code Description
No Freight Information
